DESCRIPTION

INSTALLATION

HL 2240, HL 2260 and HL 2290 are horn loaded two-way loudspeakers for array systems

for mid distance and long throw applications, both indoors and outdoors.

HS 2200 is the matched 18” subwoofer.

All trapezoidal enclosures are made of multi-ply Baltic birch plywood and nished in a very

resistant, textured, polyurea black paint.

Every enclosure shape has a 22.5° coupling angle.

Connections to ampliers are made through watertight ‘Amphenol’ 4-pole connectors.

Front grilles are made of custom perforated steel, epoxy coated, with open-cell bres and

water repellent woven fabric backing.

HL 2240, HL 2260, HL 2290

The three models only differ in their horizontal coverage angle:

40° (HL 2240), 60° (HL 2260), 90° (HL 2290).

Each speaker:

- is equipped with RCF precision transducers: two 12” woofers and a 1.5” titanium

compression driver (with 4” voice coil)

- is very compact, provides a high sound pressure level and an accurate sound reproduction

- has a 22.5° vertical dispersion and can be either used in point source congurations for

mid distances or clustered with narrower angles for long-throw applications.

HS 2200 SUBWOOFER

It is equipped with a single 18” woofer (RCF precision transducer) with a 4” voice coil.

Loudspeakers need to be installed securely by qualied personnel, respecting all safety

standards. Make sure support structures (walls / ceilings / trusses) have the necessary

mechanical characteristics for the total loudspeaker weight, without the risk of a fall that

could damage things or cause injuries. Use suitable attachments elements only.

Warning: never make arrays With more than 6 speakers (each)!

HL series speakers (and HS 2200 subwoofers) can be installed as suspended line arrays,

each including from 2 to (max.) 6 speakers. A single speaker installation is not

foreseen.

At least a ybar (that needs to be purchased, model RCF FLYBAR HL 2260) is necessary.

Line arrays can be hanged by using chains and M20 D-shackles (not included).

M10 screws for the front side and M12 screws with nuts for the rear side are included.
