RCF C 5215-66 [12/28] Specifications

12

ENGLISH

SPECIFICATIONS

CABINET: birch plywood COLOUR: black

MODEL C 5212-64 C 5212-66 C 5212-94 C 5212-96 C 5212-99

IMPEDANCE (‘full range’) 8 Ω 8 Ω 8 Ω 8 Ω 8 Ω

RMS POWER, (“full-range”) 500 W 500 W 500 W 500 W 500 W

IMPEDANCES (‘bi-amp’)

8 Ω (LF)

8 Ω (LF)

SENSITIVITY (1 W / 1 m) 98 dB 98 dB 98 dB 98 dB 98 dB

SPL (1 m) 125 dB (500 W) 125 dB (500 W) 125 dB (500 W) 125 dB (500 W) 125 dB (500 W)

WOOFER 12” (3” v.c.) 12” (3” v.c.) 12” (3” v.c.) 12” (3” v.c.) 12” (3” v.c.)

DRIVER 1.4” (2.5” v.c.) 1.4” (2.5” v.c.) 1.4” (2.5” v.c.) 1.4” (2.5” v.c.) 1.4” (2.5” v.c.)

DISPERSION (hor. x vert.) 60° x 40° 60° x 60° 90° x 40° 90° x 60° 90° x 90°

NET WEIGHT 29 kg 29 kg 29 kg 29 kg 29 kg

MODEL C 5215-64 C 5215-66 C 5215-94 C 5215-96 C 5215-99

IMPEDANCE (‘full range’) 8 Ω 8 Ω 8 Ω 8 Ω 8 Ω

RMS POWER, (“full-range”) 500 W 500 W 500 W 500 W 500 W

IMPEDANCES (‘bi-amp’) 8 Ω(LF)-8 Ω(HF) 8 Ω(LF)-8 Ω(HF) 8 Ω(LF)-8 Ω(HF) 8 Ω(LF)-8 Ω(HF) 8 Ω(LF)-8 Ω(HF)

SPL (1 m) 126 dB (500W) 126 dB (500W) 126 dB (500W) 126 dB (500W) 126 dB (500W)

WOOFER 15” (3” v.c.) 15” (3” v.c.) 15” (3” v.c.) 15” (3” v.c.) 15” (3” v.c.)

DRIVER 1.4” (2.5” v.c.) 1.4” (2.5” v.c.) 1.4” (2.5” v.c.) 1.4” (2.5” v.c.) 1.4” (2.5” v.c.)

DISPERSION (hor. x vert.) 60° x 40° 60° x 60° 90° x 40° 90° x 60° 90° x 90°

NET WEIGHT 34.8 kg 34.8 kg 34.8 kg 34.8 kg 34.8 kg

MODEL C 7312-64 C 7312-94 C 9315-64 C 9315-94

IMPEDANCE (‘full range’) 8 Ω 8 Ω 8 Ω 8 Ω

RMS POWER (‘full range’) 700 W 700 W 1000 W 1000 W

IMPEDANCES (‘bi-amp’) 8 Ω(LF)-8 Ω(HF) 8 Ω(LF)-8 Ω(HF) 8 Ω(LF)-8 Ω(HF) 8 Ω(LF)-8 Ω(HF)

AES POWERS (‘bi-amp’) 600 W (LF) - 90 W (HF) 600 W (LF) - 90 W (HF) 800 W (LF) - 90 W (HF) 800 W (LF) - 90 W (HF)

DISPERSION (hor. x vert.) 60° x 40° 90° x 40° 60° x 40° 90° x 40°

NET WEIGHT / / / /
