![Mackie DLM12 [23/29] Owner s manual](/views2/1989814/page23/bg17.png)
Owner’s Manual
23
Owner’s Manual
DLM Loudspeaker Specifications continued...
Line Input Power
US detachable line cord 100 – 120 VAC, 50 – 60 Hz, 250W
EU detachable line cord 220 – 240 VAC, 50 – 60 Hz, 250W
AC Connector 3-pin IEC 250 VAC
Safety Features
Input Protection Peak and RMS limiting,
power supply and amplifier
thermal protection
Display LEDs Defeatable front power ON,
Front load power limiter
Status Info Power supply voltage,
Core temperature
Construction Features
Cabinet PC-ABS [High-strength]
Finish High durability black paint
Handles One on top
Grille Powder-coated 20 gauge steel
Fly Points Three M10 x 17 mm
Monitor Angle 50˚ (using integrated kickstand)
Physical Properties
DLM8:
Height 12.3 in / 313 mm
Width 12.1 in / 307 mm
Depth 11.9 in / 302 mm
Weight 22 lb / 10 kg
DLM12:
Height 15.9 in / 403 mm
Width 15.3 in / 389 mm
Depth 14.3 in / 363 mm
Weight 31 lb / 14.1 kg
Mounting Methods
Floor mount, pole mount, wall mount or fly via three integrated
M10 mounting points (using M10 x 17 mm forged shoulder
eyebolts). See pages 15-17 for more information.
Options
PA-A3 Forged Shoulder Eyebolt Kit
(3 x M10 x 17 mm) P/N 2036960
SPM300 Loudspeaker Pole Mount P/N 2036970
SWM300 Swivel Wall Mount P/N 2034990
Disclaimer
Since we are always striving to make our products better by
incorporating new and improved materials, components, and
manufacturing methods, we reserve the right to change these
specifications at any time without notice.
“Mackie” and the “Running Man” figure are registered
trademarks of LOUD Technologies Inc.
All other brand names mentioned are trademarks or registered
trademarks of their respective holders, and are hereby
acknowledged.
©2012 LOUD Technologies Inc.
All Rights Reserved.
