10
1604VLZ4
1604VLZ4
4. Insert
Theseunbalanced1/4"jacksareforconnectingserial
effectsprocessorssuchascompressors,equalizers,
de-essers,orlters.Theinsertpointisafterthegain
[3]control,butbeforethechannel’sEQ[32],lowcut
[33],fader[25]andmute[30]controls.Insertcables
mustbewiredthusly:
Tip=send(outputtoeffectsdevice)
Ring = return(inputfromeffectsdevice)
Sleeve = commonground
Eventhoughchannels1–8alreadyhavedirectout[5]
jacks,insertjackscanalsobeusedaschanneldirect
outputs;post-gain,pre-lowcut,andpre-EQ.Seethe
connectorsectiononpage29showingthreewaystouse
insertcables.
5. Direct Out
Foundonlyonchannels1–8,thesebalanced1/4"
jacksdeliverthesignalfromtheveryendofthechannel
path;post-gain[3],post-EQ[32],post-lowcut[33],
post-fader[25],andpost-mute[30].Theyarethekey
playerin“splitmonitoring,”makingthe1604VLZ4
perfectforan8-trackstudio.
Split Monitoring
Withsplitmonitoring,youusethersteight
channelsforyoursoundsources:vocalmics,
drummics,keyboard/synthoutputs,guitar
effectsoutputs,thatsortofthing.Fromthere,the
channelsmanipulatethesound,butarenotassignedto
theoutputsection.Instead,they’repatchedfromthe
channel’sdirectout[5]jackstothecorresponding
multitrackinput(directout1tomultitrackinput1,2to
2,3to3,etc.).Thesignalswillnowberecordedorpass
directlythroughthemultitrack,dependingoneach
track’srecord-readystatus.
tip
This plug connects to one of the
mixer’s Channel Insert jacks.
ring
tip
ring
sleeve
SEND to processor
RETURN from processor
(TRS plug)
multitrack
machine
sound sources
direct
outputs
group
outputs
1–8 9–16
2. Line Ins
These1/4"jackssharecircuitry(butnotphantom
power)withthemicpreamps,andcanbedrivenby
balancedorunbalancedsourcesatalmostanylevel.
Youcanusetheseinputsforvirtuallyanysignalyou’ll
comeacross,frominstrumentlevelsaslowas–50dBu,
tooperatinglevelsof–10dBVto+4dBu,sincethere
is–15to+45dBofgain(60dBrange)availablefor
lineinputsviathegain[3]knob.Alwaysmakesure
toperformthelevelsettingprocedureonpage5.
Toconnectbalancedlinestotheseinputs,use
a1⁄4"Tip-Ring-Sleeve(TRS)plug,wiredasfollows:
Tip=Positive(+orhot)
Ring=Negative(–orcold)
Sleeve=Shieldorground
Toconnectunbalancedlinestotheseinputs,
usea1⁄4"mono(TS)phoneplug,wiredasfollows:
Tip=Positive(+orhot)
Sleeve=Shieldorground
3. Gain
Yesit’strue,thesecontrolsarenotinthepatchbay
sectionatall.They’refoundalongthetoprowof
knobsinthechannelstripsection.Buttheirpurpose
issocloselylinkedwiththemicandlineinputjacks
thatwecouldn’tbeartoseparatethem.Ifyouhaven’t
already,pleasereadthelevel-settingprocedureon
page5.
Gainadjuststheinputsensitivityofthe
micandlineinputs.Thisallowssignals
fromtheoutsideworldtobeadjustedto
optimalinternaloperatinglevels.
IfthesignaloriginatesthroughtheXLRjack,there
willbe0dBofgainwiththeknobfullydown,ramping
to60dBofgainfullyup.
Throughthe1⁄4"input,thereis20dBofattenuation
fullydownand40dBofgainfullyup,witha“U”(unity
gain)markat10:00.This20dBofattenuationcanbe
veryhandywhenyouareinsertingaveryhotsignal,or
whenyouwanttoaddalotofEQgain,orboth.Without
this“virtualpad,”thisscenariomightleadtochannel
clipping.
3
2
4
56
