11
Owner’s Manual
Owner’s Manual
4. Insert
Theseunbalanced1/4"jacksareforconnectingserial
effectsprocessorssuchascompressors,equalizers,
de-essers,orlters.Theinsertpointisafterthegain
[3]control,butbeforethechannel’sEQ[32],lowcut
[33],fader[25]andmute[30]controls.Insertcables
mustbewiredthusly:
Tip=send(outputtoeffectsdevice)
Ring = return(inputfromeffectsdevice)
Sleeve = commonground
Eventhoughchannels1–8alreadyhavedirectout[5]
jacks,insertjackscanalsobeusedaschanneldirect
outputs;post-gain,pre-lowcut,andpre-EQ.Seethe
connectorsectiononpage29showingthreewaystouse
insertcables.
5. Direct Out
Foundonlyonchannels1–8,thesebalanced1/4"
jacksdeliverthesignalfromtheveryendofthechannel
path;post-gain[3],post-EQ[32],post-lowcut[33],
post-fader[25],andpost-mute[30].Theyarethekey
playerin“splitmonitoring,”makingthe1604VLZ4
perfectforan8-trackstudio.
Split Monitoring
Withsplitmonitoring,youusethersteight
channelsforyoursoundsources:vocalmics,
drummics,keyboard/synthoutputs,guitar
effectsoutputs,thatsortofthing.Fromthere,the
channelsmanipulatethesound,butarenotassignedto
theoutputsection.Instead,they’repatchedfromthe
channel’sdirectout[5]jackstothecorresponding
multitrackinput(directout1tomultitrackinput1,2to
2,3to3,etc.).Thesignalswillnowberecordedorpass
directlythroughthemultitrack,dependingoneach
track’srecord-readystatus.
tip
This plug connects to one of the
mixer’s Channel Insert jacks.
ring
tip
ring
sleeve
SEND to processor
RETURN from processor
(TRS plug)
multitrack
machine
sound sources
direct
outputs
group
outputs
1–8 9–16
Theoutputsofthemultitrackarethenpatched
tothenexteightline[2]inputsonthe1604VLZ4
(multitrackout1tolineinput9,2to10,3to11,etc.).
Thesechannels(9–16)willbeassignedtothemixer’s
outputsection,deliveringthesignalstotheirultimate
destination,whichmaybeyourmixdown2-track,your
controlroomsystem,oryourheadphones.
Butlet’snotforgetthatthe1604VLZ4isa4-bus
mixer.Thesebusesleadtothesubouts[8],andare
designedtoaccomplishthetaskofgettingchannels
tothemultitrackwithoutusingthedirectoutputs.
Forexample,achannelisassignedtosubout1.
Subout1’soutputispatchedtomultitrackinput1.
Fromthere,themultitrackoutputgoestothemixer’s
channel9lineinput,aswejustdiscussed.(Hottip:
Tofeedan8-trackdeckwith4suboutputs,simplyuse
Y-cords:subout1feedstracks1and5,2feeds2and6,
3feeds3and7,and4feeds4and8.Tracksinrecord
modewillacceptthesignal,andtracksinsafemode
willignorethesignal.)
Theadvantages:Youcanassignanychanneltoany
track,withoutrepatching.Youcanassignmultiplechan-
nelstoonetrackandcontroltheoveralllevelofthat
subgroup.Youcan’tbouncetrackswithoutthisfeature.
Perhapsthebestmethodistodoboth:Usethesub
outstofeedmultichannelsubmixes(likeadrumkit)
tosomeofthetracks,andthedirectoutjackstofeed
single-channelsignals(likebassguitar)totheother
tracks.
Thepointisthatyouneverlistendirectlytothe
sourcechannels(1–8).Youlistentothemonitorchan-
nels(9–16)andthey’relisteningtothemultitrackthat
islisteningtothesourcechannels.(Makesuretoassign
themonitorchannels9-16totheL/Rmix,andnotthe
sourcechannels1-8.)Themainadvantageisthatyou
won’tbeforcedtoconstantlyrepatchyourmultitrack—
justsetitupandforgetit.You’llalsoknowforcertain
thatthesignalsareindeedgettingtothemultitrack,
sinceyou’reconstantlylisteningtoit.
Anothermethodofinterfacingamultitrackiscalled
inlinemonitoring,andrequiresadedicatedmixing
console.Eachofitschannelsisactuallytwochannels:
onecarryingthemic/linesoundsourceandtheother
carryingthemultitrackoutput.
6. Aux Sends
These1/4"jacksusuallypatchtotheinputsof
aparalleleffectsdevicesortotheinputsofstage
monitoramps.Fordetailssee
“
AuxTalk
”
onpage23.
Effects: Serial Or Parallel?
You’vehearduscarelesslytossaroundtheterms
“serial”and“parallel.”Here’swhatwemeanbythem:
“Serial”meansthattheentiresignalleavesthemixer
[insert(4)send],isroutedthroughtheeffectsdevice,
andreturnstothemixer[insertreturn].Examples:
compressor/limiters,graphicequalizers.
“Parallel”meansthataportionofthesignalinthe
mixeristappedofftothedevice(auxsend),processed
andreturnedtothemixer(stereoreturn)tobemixed
withtheoriginal“dry”signal.Thisway,multiple
channelscanallmakeuseofthesameeffectsdevice.
Examples:reverb,digitaldelay.
Dry Signal
Processed
Signal
Insert
Send
Insert
Return
Dry Signal(s)
Dry Signal(s)
Aux
Send
Aux
Return
Wet Signal
Channel Path
Mix
Stage
Output
Section
Processed
Signal
Signal Processor
(e.g., Compressor)
Signal Processor
(e.g., Reverb)
Dry Signal
Processed
Signal
Insert
Send
Insert
Return
Dry Signal(s)
Dry Signal(s)
Aux
Send
Aux
Return
Wet Signal
Channel Path
Mix
Stage
Output
Section
Processed
Signal
Signal Processor
(e.g., Compressor)
Signal Processor
(e.g., Reverb)
Dry Signal
Processed
Signal
Insert
Send
Insert
Return
Dry Signal(s)
Dry Signal(s)
Aux
Send
Aux
Return
Wet Signal
Channel Path
Mix
Stage
Output
Section
Processed
Signal
Signal Processor
(e.g., Compressor)
Signal Processor
(e.g., Reverb)
