AMERICAN DJ Quad Gem LED DMX Руководство по эксплуатации онлайн
American DJ®
6122 S. Eastern Ave.
Los Angeles CA. 90040
www.americandj.com
Rev. 5/09
User Instructions
American DJ® - www.americandj.com - Quad Gem DMX™ Instruction Manual Page 2
Unpacking: Thank you for purchasing the Quad Gem DMX™ by
American DJ®. Every Quad Gem DMX™ has been thoroughly tested
and has been shipped in perfect operating condition. Carefully check
the shipping carton for damage that may have occurred during ship-
ping. If the carton appears to be damaged, carefully inspect your x-
ture for any damage and be sure all equipment necessary to operate
the unit has arrived intact. In the event damage has been found or parts
are missing, please contact our toll free customer support number for
further instructions. Please do not return this unit to your dealer with-
out contacting customer support rst.
Introduction: The Quad Gem DMX™ is a DMX intelligent LED fixture.
When using DMX mode you can choose between a four channle mode
and a 10 channel mode. The fixture can operate in three different oper-
ating modes; stand alone, sound-active, or in a Master/Slave configu-
ration. The Quad Gem DMX™ comes with several built in programs.
When used as a stand alone unit or when used in multiples linked in a
master/slave configuration. For best results use fog or special effects
smoke to enhance the beams projections.
Customer Support: American DJ® provides a toll free customer
support line, to provide help and to answer any question should you
encounter problems during your set up or initial operation. You may
also visit us on the web at www.americandj.com for any comments or
suggestions. Service Hours are Monday through Friday 9:00 a.m. to
5:00 p.m. Pacic Standard Time.
Voice: (800) 322-6337
Fax: (323) 582-2941
E-mail: support@americandj.com
To purchase parts online visit http://parts.americandj.com
Warning! To prevent or reduce the risk of electrical shock or re, do
not expose this unit to rain or moisture.
Warning! This may cause severe eye damage. Avoid looking directly
into the light source at all times!
Quad Gem DMX™ General Information
