APart MPBD20-G [3/8] Connecting the speakers

INFO@APART-AUDIO.COM

• Screw less connector for tool-free mounting. The connector accepts wire

sections between 0.75mm² up to 2.5mm².

• Your power tap of choice can be tool-free selected.

• High intelligibility

• Mounting bracket with pre drilled holes for horizontal or 45deg tilted mounting.

• ABS plastic housing

Features and benets

Connecting the speakers

100V technology

100 Watt

15W 15W 15W 10W 10W 5W 5W 5W

Amplifier power must be equal or higher than total power of all speakers

≥ + + + + + + +

Open up the MPBD20-G

Remove the four screws from the top of the MPBD20-G
