Instruction manualMASK12(T)

Model name MASK12 (low imedance)

type

2-way professional ﬁxed installation PA

speaker, dual vent bass reﬂex

cabinet

plywood, scratch resistant textured

paint

grille powder coated perforated steel grille

woofer

12” paper cone with 75 mm vented

voice coil, 180 mm ceramic magnet,

die cast frame

high frequency horn

rotatable constant directivity horn

90°H x 70°V, 25 mm exit

high frequency driver

34 mm compression driver with

titanium diaphragm, 100 mm ceramic

magnet and kapton voice coil

mounting hardware 14 x M10 nut

nominal impedance 8 ohm

RMS power @ 8 ohm 700 watts

AES rated 350 watt

protection HF overload protection

SPL 1 watt / 1m 98 dB

SPL peak 127 dB

frequency response (-10 dB) 48 Hz - 22 Khz

connector

2 x Speakon, wired in parallel: 1+ to

1+ and 1- to 1-. 2+ and 2- are not

connected

dispersion 90° H x 70° V, rotatable horn

IP rating Indoor use only (IP40)

dimensions (h x w x d) 628 x 370 x 370 mm

weight 19.2 kg

Accessories

mounting brackets MASK12UBRA-BL,

MASK12UBRA-W, MASK12PBRA-BL
