It is recommended to point the center of the speaker to the center of the

dedicated listening area, but this is not so critical because Mask 2 has a wide

dispersion range. Before mounting the bracket on the wall or ceiling, test-t

the speaker-bracket combination to see if you reach the desired mounting

angle. Determine the position of the mounting holes using the bracket as a

template and drill the holes.

Using the appropriate mounting hardware, mount the bracket to the surface.

Mounting materials for solid brick walls are included. For other materials you

may need other hardware, available from your local hardware store.

Once all screws have been securely tightened, place the included screw

covers in place.

The angle can be determinded by the position of the bracket base and the

position of the H-hook on the half-sphere ball. The factory default force-

setting of this central screw is adjusted for moving the H-hook over the

semi-sphere with or without the cabinet being over the hook. It is allowed

to adjust the angle by moving the cabinet and the H-hook together after the

mounting has been realized. You can fasten or loosen the central screw to

inuence the turning force of the H-hook.

Wall mounting the speaker

Now slide out the rubber security piece from the back of the speaker, slide

the speaker on the H-hook of the mounting bracket. Slide the rubber part

back in place to lock and secure the cabinet. Plug the euroblock connector

into the speaker.
