APart KUBO5T-W [20/24] Design cabinet loudspeaker

Design cabinet loudspeaker

Speciﬁcations

model name KUBO3 KUBO3T

loudspeaker system full range driver unit with bass reﬂex

woofer size 3”

woofer cone material polypropylene

tweeter size N/A

nominal impedance 8 ohms 16 ohms

100V transfo power taps N/A 2.5W / 5W / 10W

70V transfo power taps N/A 1.25W / 2.5W / 5W / 10W

connector wire capacity

(connection and pass-

through)

max. wire size: 2.5 mm² (12 AWG)

frequency range 94 - 20,000 Hz

low impedance dynamic

power

40 W

RMS power 25 W

SPL at 1 W / 1 m 89 89

max SPL at 1m 101 101

dispersion angle (1000 Hz) 180°

IP rating 40

mounting system U-bracket

enclosure ABS plastic

grille main material steel

nearest RAL color code,

colour deviation can occur

black (RAL9011) / white (RAL9016)

net weight 0.97 kg / 2.14 lbs 1.18 kg / 2.60 lbs

dimensions (w x h x d) 131 x 125 x 109 mm / 5.17 x 4.92 x 4.31 inch
