11
AX Manual / english
5.1 Controls
On the rear side you will find controls
that allow detailed fine-tuning of your
loudspeakers to your particular room
acoustics and personal listening prefer-
ences. The following tips are intended
to assist you at using the controls in the
best manner.
Please note that using the controls may have a great impact on the
overall sound characteristics of your loudspeakers. We recommend us-
ing the controls with utmost care and only after several audio tests with
familiar recordings.
5.2 Tweeter Level
The ‘Tweeter Level’ works within the
frequency range of the tweeter raising
or lowering up to ±4 dB. It alters this
frequency range as a whole (see fig.).
A5X/A7X/A77X/A8X only:
5.3 High / Low Shelf EQ (Room EQs)
The other two controls operate in a dif-
ferent manner. The ‘High Shelf’ and the
‘Low Shelf’ are shelving filters, which
progressively raise or lower up to ±6 dB.
That means the shelving filters do not
alter a whole frequency band but alter
in this band: from a certain point (5kHz
respectively 300Hz in this case) the fre-
quencies are gradually being changed
(see fig.).
5. Speaker Adjustment
TWEETER LEVEL
A5X
LOW SHELFHIGH SHELF
OUTPUT
STEREOLINK
INPUT
UNBALANCED IN
BALANCED IN
CONTROLS
IN-/ OUTPUTS
0
-6 dB +6 dB
0
-6 dB +6 dB
0
-4 dB +4 dB
Serial No.
T1.6AL (230V~,50Hz)
T3AL (115V~,60Hz)
130WATTS
