Mounting these speakers has never been easier. An adjustable stainless steel mounting bracket

with extension is included in the packing. The extension piece can be used to mount the speakers

under an angle. Attach the brackets according to the picture: you can mount the speaker under a

certain angle from the wall by extending the top bracket with the supplied bracket extender.

To obtain the best performance, it is VERY important to position the column correctly, this means

that the center point of the column must be precisely directed towards the height of the listeners (or

just above it) in the appointed area. For advise in acoustics, contact your dealer.

For improved security, a special mounting rail is incorporated at the back of the cabinet. You can

use M6 at head carriage or T-bolts to attach additional safety cables or special mounting brackets

(not included).

Color code internal connector:

Common (for 100 volt use or lo-Z use): Black

Lo-Z connection: White

High power tap: Red

Medium power tap: Yellow

Low power tap: Green

Note: you can only use 1 power tap at the same time: never connect the speaker to a Lo-Z and

100 volt amplier simultaneously and never use multiple 100 volt taps at the same time. Connect

the speaker correctly as required and don’t connect the unused wires. Example: for use as a lo-Z

speaker, connect the black (negative) and white (positive) wire.
