Electro-Voice | EVID S44
EVID S44
▪ A complete matched background/foreground music
speaker solution.
▪ Large 8-inch (200 mm) woofer transducer for
substantial low frequency output.
▪ Direct connection of satellites to subwoofer —
simplifies installation wiring.
▪ Mounting brackets with wide range of motion for
surface mount satellites provide easy and secure
mounting of speaker to wall.
▪ Convenient detachable phoenix style signal
connections speed up installation time.
The EVID Compact Sound Speaker System is a very
compact full-range loudspeaker ideal for applications
requiring high-quality sound. Its shape flexibility and
size make it nearly invisible for use in background/
foreground music systems for restaurants, bars,
patios, retail, and other applications. The system
consists of a high performance surface mount 8-inch
subwoofer module with a crossover network to
support the included four (4) surface mount 2-inch
satellite speakers. The system provides for easy signal
connections at the subwoofer and can support either
4/8 ohm or 70/100v signal connections. Its high power
handling allows the system to be used in a wide
variety of environments and spaces to provide high
quality background or foreground music.
Technical specifications
EVID 2.1 EVID 40S
Frequency Response
(-10 dB):
180 Hz - 20 kHz
1
42 Hz - 300 Hz
1
Power Handling: 30 W
2
200 W
2
Sensitivity: 84 dB
1
88 dB
1
Impedance: 16 ohms Dual 8 ohm / mono
4 ohm
Maximum SPL: 100 dB
1
114 db
1
Voice Coverage (H x V): 150° x 150°
3
Omnidirectional
EVID 2.1 EVID 40S
Music Program
Coverage (H x V):
100° x 100°
4
Omnidirectional
Transducer: 50 mm (1.97 in) 200 mm (7.87 in)
Bracket Adjustment
Range (H x V):
160° x 60° Fixed
Connectors: Phoenix (2-pin) Phoenix (2-pin)
Enclosure: ABS (fire rated) Wood (MDF)
Transformer Taps: NA 100 W, 50 W, 25
W, 12.5 W
Dimensions (H x W x
D):
115 mm x 85 mm x
95 mm
(4.53 in x 3.35 in x
3.75 in)
400 mm x 400 mm
x 230 mm
(15.75 in x 15.75
in x 9.06 in)
Net Weight: (each) 0.5 kg (1.1 lb) 12.05 kg (26.55
lb)
Shipping Weight: 1 sub and 4 satellites: 18.26 kg (40.25 lb)
Included Accessories: Wall bracket; hex
wrench
Wall bracket; hex
wrench
1. Half space (wall mounting).
2. Long Term Program Rating, 3 dB greater than
continuous noise pink noise rating.
3. Average 1 kHz – 4 kHz.
4. Average 1 kHz – 8 kHz.
