Thank you for purchasing BOYA BY-F8OD!

Boya BY-F8OD is a professional omni-directioanl

condenser lavalier video/instrument microphone, which

not only perform well in video recording, but also works

good for music recording.

The frequency response favors the mid-range frequencies

of group performance while minimizing noise registering

at high and low frequencies. Omni directional pattern

helps to pickup of sounds from all directions, make sure

all sound clear and no details missed.

Feature

• For Vocal & Acoustic Guitar Applications

• Cardioid condenser microphone

• Broadcast-quality condenser mic

• XLR output connector

• Includes lapel clip, foam windscreen,windshield fur,

pouch

• 48V phantom power or 1xAA battery

• Rugged metal construction

Specifications:

Safety information

This symbol indicates that there are important

operating and maintenance instructions in the

literature accompanying your microphone.

BY-F8OD

1. Push the open switch & battery compartment

backward at the same time until they seperate;

2. Insert an AA battery to the battery compartment,

make sure that the + and – signs match the

symbols in the compartment.

3. Close the battery compartment

Professional omni directional lavalier

video/instrument microphone

35-18,000Hz

-38dB +/- 3dB / 0dB=1V/Pa，1kHz

80dB

200 Ohms

1.5V battery or 48V phantom

70 hours approximately

Off , on-flat , on-roll-off

3-pin XLR

86*63*28mm (3.4x2.5x1.1')

2m (6.6')

212g (7.5oz)

Frequency Response:

Sensitivity:

Signal to Noise Ratio:

Output Impedance:

Power Supply:

Battery Life:

Switch:

Plug:

Dimensions of power

mould(L*H*D):

Length of the

lavalier cable:

Net Weight:

FREQUENCY RESPONSE

BOYA AUDIO EQUIPMENT (SHENZHEN) CO., LIMITED

Add: A16 building, New Material Industrial Park of

Silicon Valley Power, Guanlan Town, Shenzhen, China

Tel: (86)0755-28435910

Email: sales@boya-mic.com

www.boya-mic.com

100

-20

-30

+20

-10

+10

200

500

1000

2000

5000

10000

20000

(0dB =1V/Pa, 1KHz)

7. Batteries should not be exposed to excessive heat,

such as direct sunlight, fire, or being left in a hot car.

8. Take great care when using the microphone around

moving objects or in other situations where the cable

could be suddenly tugged or pulled.

Instruction Manual

1. Please read these istructions for use thoroughly

before you use this new equipment for the first time.

It contains everything you need to know in order to

avoid damage to persons or property.

2. Heed all warnings and follow all instructions.

3. Do not use this microphone near water and clean

only with a dry cloth.

4. Only use attachments/accessories specified by the

manufacturer.

5. Refer all servicing to qualified service personnel,

Servicing is required when the apparatus has been

damaged in any way, such as, liquid has been spilled

or objects have fallen into the apparatus, the

apparatus has been exposed to rain or moisture,

does not operate normally, or has been dropped.

6. To protect the device from damage or malfunction, do

not expose this device to rain, moisture, or excessive

humidity.

5 6 7

3 4

Structure

1.Mini 3-pin XLR lavalier mic

2.Mini 3-pin XLR male mount

3.Standard XLR male mount

4.Clothing clip

5.Power mould

2 3

Package Contents

• Lavalier microphone

• Power module

• Lapel clip

• Foam windshield

• Fur windscreen

• Zipper carrying pouch

Installing Battery
