12 MULTICOM PRO-XL MDX4600/COMPOSER PRO-XL MDX2600/AUTOCOM PRO-XL MDX1600 User Manual
De-Esser Section
Type VAD (Voice-Adaptive De-esser)
MDX2600
Filter frequencies 8.6 kHz (female), 7.5 kHz (male)
Filter bandwidth program-dependent
Level reduction variable, max. 15 dB
MDX1600
Filter frequency 5-8 kHz
Filter bandwidth program-dependent
Level reduction max. 15 dB
Dynamic Enhancer Section
Type IDE (Interactive Dynamic Enhancer)
MDX4600
Filter frequency 2.5 kHz (lower cut-o frequency)
Characteristic high-pass lter (6 dB/oct.)
Boost max. 28 dB @ 7.5 kHz
MDX2600
Filter frequency 2.5 kHz (lower cut-o frequency)
Characteristic high-pass lter (6 dB/oct.)
Boost max. 28 dB @ 7.5 kHz
MDX1600
Filter frequency 2.5 kHz (lower cut-o frequency)
Characteristic high-pass lter (6 dB/oct.)
Boost variable, max. 40 dB @ 7.5 kHz
Power Supply
Mains Voltage
USA/Canada 120 V~, 60 Hz
U.K./Australia 240 V~, 50 Hz
Europe 230 V~, 50 Hz
General export model 100 -120 V~, 200 -240 V~, 50 - 60 Hz
Power Consumption
MDX4600 max. 18 W
MDX2600/MDX1600 max. 15 W
Fuse
MDX4600 100 -120 V~: T 630 mA H
200 -240 V~: T 315 mA H
MDX2600/MDX1600 100 -120 V~: T 250 mA H
200 -240 V~: T 125 mA H
Mains connection standard IEC receptacle
Dimensions/Weight
Dimensions approx. 1 ¾ x 19 x 8 ½"
approx. 44.5 x 483 x 217 mm
MDX4600
Weight approx. 5.3 lbs / 2.4 kg
Shipping weight approx. 7.9 lbs / 3.6 kg
MDX2600
Weight approx. 5 lbs / 2.3 kg
Shipping weight approx. 7 lbs / 3.2 kg
MDX1600
Weight approx. 5.3 lbs / 2.4 kg
Shipping weight approx. 7.5 lbs / 3.4 kg
BEHRINGER makes every effort to ensure the highest standard of quality. Necessary modifications are carried
out without notice. Thus, the specifications and design of the device may differ from the information given in
this manual.
