12 ULTRAGRAPH PRO FBQ6200/FBQ3102/FBQ1502 User Manual
FBQ3102
Audio Inputs
INPUTS RF-ltered, servo-balanced XLR and
¼" TRS connectors
Impedance 40 kW balanced and unbalanced
Maximum input level +21 dBu balanced and unbalanced
CMRR typ. 40 dB, >55 dB @ 1 kHz
Audio Outputs
OUTPUTS servo-balanced XLR and
¼" TRS connectors
SUBWOOFER OUT balanced XLR connector
Crossover frequency variable, 30 - 200 Hz
System Specications
Frequency response 10 Hz to 30 kHz, ±3 dB
S/N ratio 22 Hz to 22 kHz >94 dB @ +4 dBu
Distortion (THD) typ. 0.006% @ +4 dBu, 1 kHz, Gain 1
Crosstalk typ. -65 dB @ 1kHz
Roll-O Filter Section
Type 12 dB/oct., Butterworth
Input variable (-15 dB to +15 dB)
Low Cut variable (10 Hz to 400 Hz)
High Cut variable (2.5 kHz to 30 kHz)
Graphic Equalizer
Type analog 31-band equalizer
Frequency range 20 Hz to 20 kHz in 31 1/3-octave bands
(ISO frequencies)
Bandwidth 1/3 octave
Control range ±6 dB or ±12 dB (switchable)
Limiter Section
Attack/Release —
Threshold —
LED meter —
Noise Generator
Type —
LED level meter —
Function Switches
FBQ activates the FBQ Feedback
Detection System
Audio In/Out switch to bypass the equalizer functions
I/O Meter In/Out switches the meter display from input
to output
Range shift of the maximum cut/boost range
for all 31/15 bands
Low Cut —
Limiter —
Pink Noise —
Subwoofer —
Indicators
Input/output level 12-segment LED display: -30/-24/-18/
-12/-6/-3/0/+3/+6/+9/+12 dB/CLIP
Subwoofer —
Power Supply
Mains Voltage
USA / Canada 120 V~, 60 Hz
Europe / U.K. / Australia 230 V~, 50 Hz
Japan 100 V~, 50 - 60 Hz
General Export Model 120/230 V~, 50 - 60 Hz
Power consumption 35 W
Fuse 100 - 120 V~: T 630 mA H
200 - 240 V~: T 315 mA H
Mains connection standard IEC receptacle
Dimensions / Weight
Dimensions (H x W x D) 150 x 89 x 482.6 x mm (5.9 x 3.5 x 19")
Weight 2.64 kg (5.8 lbs)
