Page 7 of 9
Specications
EPQ2000
Output Power
RMS
Stereo
8 Ω per channel, stereo 500 W
4 Ω per channel, stereo 700 W
Bridged Mono
8 Ω bridge mode 1400 W
Peak Power
Stereo
8 Ω per channel, stereo 600 W
4 Ω per channel, stereo 1000 W
Bridged Mono
8 Ω bridge mode 2000 W
System
Controls
Front Power switch GAIN control
(channels 1 and 2)
Rear CROSSOVER switch,
MODE switch, LIMITER switch
Indicators
Power Blue LED
Limit (per channel) Blue LED
Signal (per channel) White LED (-20 dB, -10 dB,0 dB)
Connectors
Inputs Balanced XLR, ¼" TRS , RCA
Input impedance 10 kΩ unbalanced, 20 kΩ balanced
Outputs Touch-proof binding posts,
professional speaker connectors
Output circuit type Class H, 2-tier
Distortion < 0.01%
Frequency Response 20 Hz - 20 kHz, +0/-1 dB
Damping Factor > 220 @ 8 Ω
Signal-to-Noise >100 dBA
Circuit Protection
Cooling Continuously variable speed fan
Back-to-front air ow
Amplier protection Full short-circuit, open-circuit,
thermal, and HF protection.
Stable into reactive or
mismatched loads
Load protection On /o muting, DC-fault power
supply shutdown
Power supply / Voltage (Fuses)
USA / Canada 120 V~, 60 Hz (T 20 A H 250 V)
UK / Australia 220-240 V~, 50/60 Hz
(T 8 A H 250 V)
Europe 220-240 V~, 50/60 Hz
(T 10 A H 250 V)
Japan 100 V~, 50/60 Hz (T 20 A H 250 V)
Power consumption 2200 W
Mains connector Standard IEC receptacle
Dimensions/Weight
Dimensions (H x W x D) 3.7 x 19.0 x 10.6"
94 x 483 x 269 mm
Weight 15.4 lbs / 7.0 kg
EPQ1200
Output Power
RMS
Stereo
8 Ω per channel, stereo 250 W
4 Ω per channel, stereo 425 W
Bridged Mono
8 Ω bridge mode 850 W
Peak Power
Stereo
8 Ω per channel, stereo 320 W
4 Ω per channel, stereo 600 W
Bridged Mono
8 Ω bridge mode 1200 W
System
Controls
Front Power switch GAIN control
(channels 1 and 2)
Rear CROSSOVER switch,
MODE switch, LIMITER switch
Indicators
Power Blue LED
Limit (per channel) Blue LED
Signal (per channel) White LED (-20 dB, -10 dB,0 dB)
Connectors
Inputs Balanced XLR, ¼" TRS , RCA
Input impedance 10 kΩ unbalanced, 20 kΩ balanced
Outputs Touch-proof binding posts,
professional speaker connectors
Output circuit type Class AB
Distortion < 0.01%
Frequency Response 20 Hz - 20 kHz, +0/-1 dB
Damping Factor > 220 @ 8 Ω
Signal-to-Noise >100 dBA
Circuit Protection
Cooling Continuously variable speed fan
Back-to-front air ow
Amplier protection Full short-circuit, open-circuit,
thermal, and HF protection.
Stable into reactive or
mismatched loads
Load protection On/o muting, DC-fault power
supply shutdown
Power supply / Voltage (Fuses)
USA / Canada 120 V~, 60 Hz (T 15 A H 250 V)
UK / Australia 220-240 V~, 50/60 Hz
(T 8 A H 250 V)
Japan 100 V~, 50/60 Hz (T 15 A H 250 V)
Power consumption 1300 W
Mains connector Standard IEC receptacle
Dimensions/Weight
Dimensions (H x W x D) 3.7 x 19.0 x 10.6"
94 x 483 x 269 mm
Weight 14.8 lbs / 6.7 kg
EUROPOWER
EPQ2000
EPQ1200/EPQ900
EPQ450/EPQ304
