Page 3 of 3
For service, support or more information contact the BEHRINGER location nearest you:
Europe
MUSIC Group Services UK
Tel: +44 156 273 2290
Email: CARE@music-group.com
USA/Canada
MUSIC Group Services NV Inc.
Tel: +1 702 800 8290
Email: CARE@music-group.com
Japan
MUSIC Group Services JP K.K.
Tel.: +81 3 6231 0454
Email: CARE@music-group.com
Technical specifications and appearances are subject to change without notice and accuracy is not guaranteed. BEHRINGER is part of the MUSIC Group (music-group.com). All trademarks are the property of their respective owners. MUSIC Group accepts no liability for any loss
which may be suffered by any person who relies either wholly or in part upon any description, photograph or statement contained herein. Colors and specifications may vary from actual product. MUSIC Group products are sold through authorized fullfillers and resellers only.
Fullfillers and resellers are not agents of MUSIC Group and have absolutely no authority to bind MUSIC Group by any express or implied undertaking or representation. This manual is copyrighted. No part of this manual may be reproduced or transmitted in any form or by any
means, electronic or mechanical, including photocopying and recording of any kind, for any purpose, without the express written permission of MUSIC Group IP Ltd. ALL RIGHTS RESERVED. © 2012 MUSIC Group IP Ltd. Trident Chambers, Wickhams Cay, P.O. Box 146, Road Town,
Tortola, British Virgin Islands. 985-10000-00385
5.5" woofer
0.5" high-
resolution tweeter
Multi-purpose mount
bracket
Level control with
power/clip LED
Link Output
connects
additional CE500As
Mic/Line input (XLR)
Power switch
IEC power socket
CD Input RCA jacks
SPECIFICATIONS
Components
Tweeter ½"
Woofer 5 ½"
OUTPUT POWER
RMS @ 0.1 % THD 50 W
Peak Power 80 W
AUDIO INPUTS
MIC/LINE XLR, balanced
Input impedance 27 kOhm
Sensitivity -40 dB to +10 dB
CD/TAPE RCA Input impedance 27 kOhm
AUDIO OUTPUT
LINK OUTPUT XLR, balanced
SYSTEM DATA
Frequency range 60 Hz – 23 kHz (-10 dB)
Crossover frequency 5 kHz
Max. sound pressure level 112 dB
Limiter optical
POWER SUPPLY
Power consumption max. 150 W
Mains connector IEC standard receptacle
FUSE
100 - 120 V~: T 2.5 A H 250 V
200 - 240 V~: T 1.5 A H 250 V
DIMENSIONS/WEIGHT
Dimensions (H x W x D) 12.5 x 7.7 x 7.8"
318 x 195 x 197 mm
Weight 15 lbs / 7 kg
Please note these specications are preliminary and conceptual in nature,
and as such are subject to change as product development progresses.
This information is supplied for market research purposes only and is not
to be made public in any manner. This document is solely the property of
The MUSIC Group, or one of its subsidiaries, and must be surrendered upon
request of the owner.
CE500A-BK
CE500A-WH
