6 Discreet Acoustics Modular PLUS Series

Installation and Connection

All Discreet Acoustics Modular Capsule Modules are condenser microphones and therefore

require a power supply (phantom power). The Installation Modules have been designed for

connection to microphone inputs with 9 to 52 V phantom power.

1) Screw the Capsule Module onto the Installation Module. The screw thread is relatively

fine and therefore very smooth-running. Make sure not to tilt the capsule when placing it

on the Installation Module thread because this would damage the thread.

2) To lock the capsule, use a single drop of commercial minimum-tack screw locking

adhesive that allows you to unscrew the capsule later if needed.

3) For better visibility put the LED-Ring Expansion between the Installation Module and the

Microphone Capsule.

(The LED-Ring Expansion is enclosed to the Installation Module.)

NOTE

UNWANTED NOISE

Before replacing a Capsule Module, be sure to switch your sound system OFF in order to

prevent unwanted noise.

Choose the Phantom Power Adapter according to your application.

PAESP M (page 13), PAE5 M (page 14) or PAE M (page 15).

4 Installation and Connection

Capsule Modules
