Antari FT-100 [11/32] Technical specifications

Step 1: Disconnect AC power.

Step 2: Flip breaker to ON position.

Step 3: Turn on machine for testing.

Breaker

120V = 15A 250V

230V = 7A 250V

Technical Specifications

Input voltage US 120V

EU 230V

UK 240V

JP 100V

Breaker 120V = 15A 250V

230V = 7A 250V

Heater 1500W

Warm-up time 10 min. (approx.)

Output 20,000 cu.ft/min

Max. operating time 1 min. at 100% output, 60 mins at continuous output

Fluid tank capacity 6 L

Fluid consumption 100 ml/min

Compatible fluid Antari FLP water-based fluid

Control option DMX 512, Manual, Timer, Wireless remote

DMX channels 1 channel

Power connection Neutrik Powercon

DMX data connection 5-pin XLR

Dimension L 580 x W 278.2 x H 264.5 mm

Dry weight 14.6 kg
