CEILING LOUDSPEAKER
COLOUR KLEUR COULEUR POWER IMPEDANCE
Black Zwart Noir Common
RED ROOD ROUGE 1.5 Watt 6.66 KΩ
GREEN GROEN VERT 3 Watt 3.33 KΩ
BROWN BRUIN BRUN 6 Watt 1.66 KΩ
CM6T
WWW.APART-AUDIO.COM INFO@APART-AUDIO.COM
• Type : 2 - Way HiFi
• Woofer : 6.5” Enforced Polypropylen
• Tweeter : 1” Silk Dome
• Rated Power RMS : 6 W / 100Volt
• Music Power RMS : 10 W / 100Volt
• Rated Power RMS : 40 W / 16Ω
• Music Power RMS : 60 W / 16Ω
• Sound Pres. Level (SPL) 1W/1M : 92dB
• Frequency range : 60 Hz - 20 kHz
• Trafo Power Tappings : 6 - 3 - 1.5W
• Dispersion @ 1-4-8 KHz : 180°- 80° - 45°
• Dimensions outside Ø : 205MM
• Dimensions Cutout Ø : 183MM
• Depth : 80MM
• Weight : 1.6Kg
Technical Specifications
The APart CM6T 2-way built-in loudspeaker can be
used as a 16 Ohm or 100 Volt loudspeaker. In 16 Ohm use,
you can connect up to 4 loudspeakers in parallel on each channel of a
standard 4 Ohm amplier. For 100 use, the CM6T is equipped with a high-
quality 6 Watt 100 Volt transformer with several power tappings. Therefore
it can be used with high ceilings or places where more back ground noise
is present. The loudspeaker has a 6 ½” enforced Polypropylen woofer what
results in a very low distortion. To complete the sound a 1” tweeter has been
integrated. It makes the CM6T very suitable for the distribution of microphone
calls and back ground music. The housing is made of high quality ABS.
The woofer is made out of enforced polypropylen, what makes it moisture-
proof. The standard colour is white. From 12 pieces on, the loudspeakers
can be painted optionally in any other RAL colour
Power Tappings
6 6 6 3 3 3 1.5 1.5++ + + + + +30 Watt =
40Watt Amplier
Amplier power must be higher than total power of all speakers.
Het versterkervermogen moet hoger zijn dan de som van de vermogens van de luidsprekers.
La puissance de l’amplicateur doit etre plus élevée que la puissance totale des haut parleurs.
100 Volt Technology
16 ohm Technology
Mounting the loudspeaker
16Ω 16Ω 16Ω 16Ω 16Ω 16Ω 16Ω 16Ω
4Ω 4Ω
Disconnect 100Volt transformer
16 ohm connection
The loudspeaker is easy to install,
due to its simple, quick mounting system
3 screws which are hidden behind the loud-
speaker grill, what gives the loudspeaker a
modern and striking design.
Cutout Ø : 183 MM
Remove the grill before mounting.
You can see four Philips head screws.
Use these screws to thigthen the dog-ears.
Picture shown is the CMS20T
