APart MASK4T [4/8] Mask series

MASK SERIES

WWW.APART-AUDIO.COM

This Intelligent mounting system will be your helpful partner to install your MASK 4 and 6

loudspeakers in a very safe and easy way.

Mounting and aiming your MASK will be done like a snap with your ﬁngers.

1) First attach the base plate to the wall or ceiling, keeping in mind to which direction you

will have to swing your MASK.

2) Fix the shaft/ball system to the snap on plate by means of the XXL nut.

3) Thread the assembled snap-on unit onto your MASK loudspeaker as far as it goes and

tighten it ﬁrmly.

4) Adjust the MASK’s to the desired position and fasten the XXL nut in such way, you can

hardly move your MASK.

5) Hook into the Intelli-mount base plate.

Once hooked and aimed in the ﬁnal direction you can fasten the XXL nut, so your MASK

won’t move ever again.

To secure the whole system, insert the security screw at the top and thread well.

When you mount your MASK to the ceiling, this screw must be inserted.

Minimum distance to ceiling/wall from the top of the base plate:

• MASK4 Intelli-mount : 45mm

• MASK6 Intelli-mount : 90mm

Make sure the mounting surface can support sufﬁcient weight.

Use only industry-accepted materials and mounting methods.

Intelli-mount

Security screw

XXL nut

Shaft/Ball

Snap-on-plate

Base plate

Snap-on-plate
