Intelligent • APC circuitry constantly analyses incoming music signals and keeps dynamics

alive.Anadditionalultrafastpeaklimiteravoidsamplierclippingincasesomeonehitsthe

inputstoohard.Pleaseremember,thisisamusicalamplier,pleaseleavesomeheadroom

and enjoy the music.

Bridgeorstereomode:morethandoubletheoutputpowerandconvertthisamplierintoa•

monoblockamplierwithonepushonabutton.Minimum load impedance is 8 ohms in

bridge mode.

Protectioncircuitry:theprotectioncircuitryisanotheruniquedesignfeatureofthisampli-•

er:togetherwiththeAPCcircuitry,outputsignalsareconstantlymonitoredbytheprotection

circuits, and speaker outputs will be cut in case of extreme overload, short circuits, DC offset,

overheating…Thiscircuitisalsocapable(withincertainlimits)ofreducingtheinputsignalto

prevent clipping, distortion and other musically destructive situations. We have done our best to

makesurethisamplierwillproducecleanpower,butit is also the user who is responsible

for the nal result: the APC circuitry can not clean up a clipped input signal, in other

words: what goes in, comes out. Don’t forget to set the impedance selector correctly for

both channels and remember to divide the speaker’s impedance by a factor 2 if you are

planning to use the amplier in bridge mode ! Example in bridge mode: speaker load = 8

ohms, set channel 1 impedance selector to 8 : 2 = 4 ohms setting (4 – 8 ohms).

Versatileinputandoutputconnectorcongurationwithbalancedandunbalancedinputsand•

additionallinelevelsignaloutputsforlinkingthesignaltootherdevicesforincreasedexibility.

Thespeakeroutputterminalsacceptspeakercablesaswellas4mmbananaplugs.

Groundliftswitchtoenableyoutondthecauseofsystemgroundloopsincaseofhumor•

excessive noise.

2. Features
