Invotone DM300PRO Руководство по эксплуатации онлайн
PROFESSIONAL DYNAMIC MICROPHONE
INVOTONE DM-300 PRO microphone, the
structure and the material is designed specially for
mobile-show, the mesh with a copper-solder structure,
the body with a zinc-alloy material and a bright,
smooth surface treatment, experience of long time
using for outdoor.
Specifications
Element: Dynamic
Polar Pattern: Uni-Directional
Frequency: 60Hz~16kHz
Sensitivity: -55dB±3dB(0dB=1V/Pa at 1kHz)
Output impedance: 300Ω±30% (at 1kHz)
Frequency Response Graph
(dB)
(Hz)
Frequency Response Graph
Connecting and disconnecting the
microphone cable
1. Insert the XLR connector into the microphone. If
necessary, rotate the connector to align the key on
the connector and the groove in the microphone.
Push the connector into the microphone until it
clicks.
2. To disconnect the cable and microphone, grasp
the connector while depressing the tab. pull the
connector away from the microphone.
Usage
Stage
Monitor
Microphone
Sound
Source
Loudspeaker
1. For the best Gain-before-feedback and isolation
from undesired background noise, aim the
microphone, toward the sound resource and away
from undesired sound resource.
2. Do not cover any part of the grille with your hand,
covering the grille alters the sound and distorts
the polar pattern increasing the chance for
feedback.
Cautions
1. If the head of the microphone is covered by hand
or brought close to the speaker, a howling sound
may be generated. To prevent this, first decrease
the volume, then place the microphone so that it is
not pointed to the speaker and that there is a
sufficient distance between the microphone and
speaker.
2. It is important to keep foreign particles out of the
grill and the windscreen because they may alter
the frequency response of the microphone. The
grill shall be periodically cleaned using warm,
soapy water, rinsed with plain water and let dry
before replacing.
3. Due to the high sensitivity of the cartridge, do not
drop it from high or apply strong shock to it.
4. To maintain the sensitivity and quality of sound
reproducing, avoid exposing it to moisture and
extreme temperatures.
