4. DMX Mode
Press the “MODE”, the LED display will show as below, enter to LED DMX mode main interface.
Lightly press the “SETUP”, enter into DMX address, DMX working mode setting.
Sheet 6 DMX mode settings
Setting options
Operation instruction
DMX address setting (1 -512), through UP or DOWN set the address
Through UP or DOWN select CH1, CH4, CH6, CH7 mode
Working mode 1:
Sheet 7 The DMX mode function sheet of CH3
CHANNELS VALUE FUNCTION
1 0-255
White(whole 0-100%
Working mode 2:
Sheet 8 The DMX mode function sheet of CH6
CHANNELS VALUE FUNCTION
1 0-255
part1(bottom right
2 0-255
part2(bottom left
3 0-255
part3(upper right
4 0-255
part4(upper left
Working mode 3:
CHANNELS VALUE FUNCTION
1 0-255
Part1(bottom right
2 0-255
Part2(bottom right
3 0-255
part3(upper right
4 0-255
part4(upper left
5 0-255 master dimming
0-9 no use
10-255 strobe, the greater the value,the higher the frequency
6
Working mode 4:
Sheet 9 The DMX mode function sheet of CH7
CHANNELS
VALUE FUNCTION
1 0-255
Part 1(bottom right
2 0-255
Part 2(bottom left
3 0-255
Part 3(upper right
4 0-255
Part 4(upper left
5 0-255 Master dimming
0-39 No use
40-59 Built-in programs 1
60-79 Built-in programs2
80-99 Built-in programs3
100-159 No use
160-179 Sound active 1
180-199 Sound active 2
200-219 Sound active 3
220-255 Sound active 4
7 0-255 Built-in programs: strobe or speed; sound active:sound active sensitivity
6
