ST mode: inthis mode ,press Prog select once, program will
executed one step
the DISPLAY will show the information.
AS mode: program is executed according to the music rhythmsand
DISPLAY
shows the steps
AP mode; program is executed automatically and DISPLAY shows the
step. You
can adjust the chasing speed using TAP SYNC or
Speed control.
WARNING
1.to prevent fire or shock hazard, do not expose this
apparatus to
rain or moisture.
2.this apparatus must be earthed.
3.if the fuse is bad, please must use the same type
Described in
the operating instruct
ions
4.if the apparatus is out of order, do not attempt to service it yourself.
Sent back to your supplier for repairing .
OPERATING INSTRUCTIONS
1. Confirm the loading and power is connected then turn on the power switch.
2. Press Mode select to select desired mode from Hold dimmer/
Hold sound/
Prog sound/prog
Speed/Auto sound/Auto speed/
Memory.
HOLD DIMMER: channel output is controlled by channel dimmer
control and
master control.
Corresponding
indicator is lighting.
HOLD SOUND: corresponding indicator is lighting. Channel
output is
controlled by channel
control and the
music sensitivity is
adjusted by the AUDIO LEVEL control.
PROG SOUND: you can select desired program from 42 pre-set
using Prog.
Select button. Press
button once, program will be increased.
Prog select
press
and hold it one
second ,program will be
increased
10 steps pre second. Press Prog select+Mode
Select
then program will be decreased. Corresponding
indicator is
lighting.
Chasing speed is controlled
by audio single.
PROG SPEED: corresponding indicator is lighting. the way is
same as
PROG SOUND but the
chasing speed is
controlled by Speed
control
or Tap sync.
AUTO SPEED: operation according to Prog speed. in this mode
each program
will be execut
Ed fourt times. Then
go to next program.
corresponding indicator
is lighting.
AUTO SOUND: operation is same as Auto speed. each program
will be executed
Four times.
MEMORY: in this mode ,you can select desire operating
mode from
Program/manual/Auto
sound/Auto speed.
Corresponding to digit
indicate "PR,ST, AS ,AP."
Press and hold
Prog select ,then press
Stand by
once. PROG DISPLAY will show present operating
mode. Press Stand by once more ,next mode will be selected.
release Prog select
the selected mode will be executed.
PR mode: press Prog select till "0 1"appear in DISPLAY, adjust
Master
dimmer control or cha
nnel dimmer control to meet
User's
Will
show "02".you can make
program in this way till "32" appears.
Now exit from
"PR" mode and engage in other mode, if you fail
in
certain step, you should restart
programing, otherwise
not
effective.
requirement. press Prog select button, the D
ISPLAY will flash 4
times continuously, which means it
is memorized and DISPLAY
Dimensions................................................................482x132x126.5mm(19"x 3U).
Weight ......................................................................4.5kg.
3.Full on and flash: press Full on button to activate full on
Function of all
output. Press flash button to
Activate full on function of
channel. These two
Functions are effective in any mode.
4.Stand by: press the button once to turn off all output. Press it
Once more to
Exit stand by. The indicator will change
from "flash" to "off".
5.Audio input select: you can select audio signal from mic or audio
line input
press Prog select and turn off the
power, wait some second
turn on the power, now
the DISPLAY show "1"or "E".press
Mode select
once, audio signal will be changed. and the
DISPLAY will change accordingly. press it once
more, audio
signal will be changed once more.
