Battery & Wireless DMX Outdoor Bar, 8*Tri-3W

User Manual

Our Battery & Wireless DMX Outdoor Bar offers very nice and bright effect as an architectural wall wash or for

performance stages where traditional stage lighting emits a lot of heat onto performers. Very smooth field with rich

palettes of color created by mixing the Red, Green and Blue LEDs. Please read the manual before operation.

A. SPECIFICATION

1. Voltage: AC 100V-240V, 60Hz/50Hz

2. Power Consumption: 40W

3. LED: 8*Tri-3W

4. Beam Angle: 40°C

5. Operation mode: LED display

6. Control Feature: Built-in programs, Auto running, DMX 512, Master/slave mode, Static color and Charge mode

7. DMX channels: 3, 5, 7 CH

8. IP Rate: IP 66

9. N.W: 4.46kgs

10. Dimension: 700*120*130 MM

11. Stand by time: 5.5 hours（RGB）

12. Charging time: 6.5 hours（LED blackout when the device is being charged）

B. OPERATION

This fixture is with rich effect programs, LED dislay for easier operation, there are six working modes:

 Built-in programs mode

 Auto running mode

 Master/slave mode

 DMX mode

 Static color mode

 Charge mode

Press the “MODE” button can switch the 6 working modes.

1. Built-in Programs Mode

Pr.1

Static color program

Pr.2

Three colors fading

Pr.3

Seven colors fading
