Cakewalk VS-20 [31/52] Set tempo

From initial settings to recording

1. In Guitar Tracks 4’s toolbar, double-click the tempo display and enter the desired tempo.

Enter a numerical value from your computer keyboard, and press the Enter key to confirm it.

fig.metro02.eps

This completes preparations for recording.

7. Set tempo.

VS-20_e.book 31 ページ２０１０年１月１８日　月曜日　午前９時８分
