4. DESCRIPTIONS

DRIVE

Controls the saturation level. The saturation effect is increased when the

knob is turned to the right.

LEVEL

Controls the overall volume when the effect is on. Volume is increased

when turned to the right and decreased when turned to the left.

The low end is increased when turned to the right and reduced when

turned to the left.

MID

The mid-range is increased when turned to the right and reduced when

turned to the left.

The high-end is increased when turned to the right and reduced when

turned to the left.

PRESENCE

When the knob is turned to the right, the super high frequency region

is emphasized. When the knob is turned to the left, the super high

frequency region is eliminated.

INPUT

Turning the switch to HI increases the input level and saturation, while

turning the switch to the LO side reduces saturation.

HI is generally used for low output devices, such as single coil pickups.

LO is used for high output devises, such as hum-bucking pickups. How-

ever, select a suitable position for the sound you desire.

LED Indicator

When the effect is on, the LED indicator light will be illuminated.

Foot Switch

Switches between effect and bypass.
