M-Audio Trigger Finger Pro [13/97] Set up trigger finger pro with your software

3. Set Up Trigger Finger Pro with Your Software

Trigger Finger Pro with Your DAW

To set up Trigger Finger Pro as a controller for your digital audio workstation (DAW):

1. Connect Trigger Finger Pro to your computer using a standard USB cable. (If you are

connecting Trigger Finger Pro to a USB hub, make sure it is a powered hub.)

2. Power on Trigger Finger Pro.

3. Open your DAW.

4. Open your DAW's Preferences (or Options, Device Setup, etc.), and select Trigger

Finger Pro as your controller. Make sure that MIDI Port 1 is enabled for standard MIDI,

MIDI Port 2 is enabled for Mackie Control or HUI communication, and MIDI Port 3 is

disabled or not shown (Trigger Finger Pro uses this port to communicate with Arsenal, if

you are using Arsenal).

5. Turn Trigger Finger Pro's Value Dial to browse through the available Presets, and then

push the third Function Button (Load) to select one that corresponds to your DAW.

Your Trigger Finger Pro can now communicate with your DAW.

To set up Arsenal within your DAW, see the following section, Trigger Finger Pro with

Arsenal.

Important: If you are using Arsenal and AIR Drums, we recommend using a Preset

whose name includes Arsenal. If you are using Hybrid 3.0, we recommend using a Preset

whose name is a scale (e.g., A Major, C Minor, etc.); these Presets are tailored for

melodic synths. You can use Arsenal presets with Hybrid 3.0 to automap Hybrid 3.0's

controls, but the pads' mapping will be different.
