Meat Grinder | UGR-468

ENGLISH

OPERATION OF THE DEVICE

Assembly

1. Press the fasten button hold the head and insert it into the inlet (when

inserting plus pay attention the head must be slanted as per arrow indicat-

ed on the top, see ﬁg.1), then move the head anticlockwise so that the head

being fastened tightly. There will be lock when you screwed to the handle.

(ﬁg.2)

2. Place the snake into the head, long end ﬁrst, and turn to feed the screw

slightly until it is set into the motor housing (ﬁg.3).

3. Place the cutting blade onto the snake shaft with the blade facing the front

as illustrated (ﬁg.4). If it is not ﬁtted properly, meat will not be grinded.

4. Place the desired cutting plate next to the cutting blade, ﬁtting protrusions

in the slot (ﬁg.5).

5. Support or press the centre of the cutting plate with one ﬁnger then screw

the ﬁxing ring tight with another hand (ﬁg.6). Do not over tighten.

6. Place the hopper plate on the head and ﬁx it into position (Fig. 7)

7. Install the assembled meat grinder on a ﬁrm and level surface. When, make

sure that air can freely approach the bottom and the sides of the housing to

ensure sufﬁcient ventilation.
