If the appliance is installed with the hinges next to a wall
Fig. 5 (4)
, the distance between appliance and wall has to be at
least 40 mm. This corresponds to the projection of the handle
when the door is open.
4.5 Disposing of packaging
WARNING
Danger of suffocation due to packing material and plastic film!
u
Do not allow children to play with packing material.
The packaging is made of recyclable materials:
-
corrugated board/cardboard
-
expanded polystyrene parts
-
polythene bags and sheets
-
polypropylene straps
-
nailed wooden frame with polyethylene panel*
u
Take the packaging material to an official collecting point.
4.6 Connecting the appliance
NOTICE
Risk of damage to the electronic control system!
u
Do not use stand-alone inverters (conversion of d.c. to a.c./
three-phase) or energy saving plugs.
WARNING
Fire and overheating hazard!
u
Do not use extension cables or multiple socket outlets.
The type of current (alternating current) and voltage at the
installation site have to conform with the data on the type plate
(see Appliance at a glance).
Connect the appliance only with a properly installed
socket outlet with earthing contact. The socket outlet
must be fused with 10 A or higher.
It must be easily accessible so that the appliance can
be quickly disconnected from the supply in an emer-
gency. It must be outside the area of the rear of the
appliance.
u
Check the electrical connection.
u
Plug in the power plug.
4.7 Switching on the appliance
u
Press the On/Off button
Fig. 3 (1)
.
w
The appliance is switched on. The temperature display and
Alarm symbol
Fig. 3 (6)
flash until the temperature is cold
enough.
5 Control
5.1 Brightness of the temperature
display
You can adjust the brightness of the temperature display to the
light conditions of the room in which the appliance is installed.
5.1.1 Setting the brightness
The brightness is adjustable between h 0 (minimum brightness)
and h 5 (maximum brightness).
u
Activate setting mode by pressing the SuperFrost button,
Fig. 3 (4)
, for approx. 5 sec.
w
The Menu symbol is shown on the display,
Fig. 3 (7)
.
w
c flashes on the display.
u
Use the adjustment button,
Fig. 3 (2)
, to select h.
u
Briefly confirm with the SuperFrost button,
Fig. 3 (4)
.
w
The display shows the last set brightness value.
u
Use the adjustment button,
Fig. 3 (2)
, to set the desired
value from h 0 to h 5.
w
The brightness is set.
u
Deactivate the setting mode by pressing the On/Off button,
Fig. 3 (1)
, twice.
w
The temperature display shows the temperature again.
5.2 Child proofing
The child-proofing function enables you to make sure that the
appliance is not inadvertently switched off by playing children.
5.2.1 Setting the child lock
To switch on the function:
u
Activate setting mode by pressing the SuperFrost button,
Fig. 3 (4)
, for approx. 5 sec.
w
The Menu symbol is shown on the display,
Fig. 3 (7)
.
w
c flashes on the display.
u
Briefly confirm with the SuperFrost button,
Fig. 3 (4)
.
w
c1 appears on the display.
u
Briefly confirm with the SuperFrost button,
Fig. 3 (4)
.
w
The child lock symbol,
Fig. 3 (8)
, lights up on the
display.
w
c flashes on the display.
w
The child lock function is switched on.
To cancel setting mode:
u
Briefly press the On/Off button,
Fig. 3 (1)
.
w
The temperature display shows the temperature again.
To switch off the function:
u
Activate setting mode by pressing the SuperFrost button,
Fig. 3 (4)
, for approx. 5 sec.
w
The Menu symbol is shown on the display,
Fig. 3 (7)
.
w
c flashes on the display.
u
Briefly confirm with the SuperFrost button,
Fig. 3 (4)
.
w
c0 appears on the display.
u
Briefly confirm with the SuperFrost button,
Fig. 3 (4)
.
w
The child lock symbol,
Fig. 3 (8)
, goes out.
w
c flashes on the display.
w
The child lock function is switched off.
To cancel setting mode:
u
Briefly press the On/Off button,
Fig. 3 (1)
.
w
The temperature display shows the temperature again.
5.3 Temperature alarm
The audible alarm sounds if the freezer temperature is not cold
enough.
The temperature display and the alarm symbol
Fig. 3 (6)
flash
at the same time.
The audible alarm is automatically silenced, the alarm symbol
Fig. 3 (6)
goes out and the temperature display stops flashing
when the temperature is sufficiently cold again.
If the alarm status persists: (see Malfunction).
5.3.1 Muting the temperature alarm
The audible alarm can be muted. When the temperature is
sufficiently cold again, the alarm function is active again.
u
Press alarm button
Fig. 3 (9)
.
w
The audible alarm is silenced.
Control
6
