12
Equipment
Interior light (except model GT 1456)
The interior light switches on automatically when the lid is opened
and switches o again when it is closed.
Bulb data: 15 W (never use a
bulb rated at m o r e t h a n 15 W ).
The voltage should agree with
the details on the type plate.
Bulb tting: E 14.
Replacing the bulb:
Disconnect from the mains
or switch o or unscrew
the fuse.
- Remove the cover panel in
the direction of the arrow.
- Change the bulb.
- Replace the cover panel.
Baskets
T h e b a s k e t s m a ke i t e a s i e r f o r y o u t o s o r t f o o d .
The baskets can be suspended in
the frame of the freezer by their
handles.
The baskets can also be placed on
top of one another, by sitting the
upper basket on the handles that
are folded inwards.
Press the handle downwards, lift and
tilt inwards.
Lock
The lock is equipped with a safety
mechanism.
Locking the appliance:
1 Press the button and keep it de-
pressed.
2 Turn the key 90°.
Freezer tray
With the freezer tray, small fro-
zen food items (berries, herbs,
chopped vegetables) can be
gently frozen.
Spread the frozen items out on
the freezer tray (pieces of fruit do
not stick together and so keep
their shape).
The freezer tray can either be
suspended on the basket or can
be slid into the interior container
and used as a partition (except
model GT 1456).
Cold-storage accumulators (depending on options)
In the event of a power failure, the cold-storage accumulator delays
the temperature increase in the freezer compartment.
When switching on for the rst time, insert the accumulator in
direct contact with the interior container side walls and the interior
container oor so that it freezes quickly.
When the accumulator is com-
pletely frozen, position it at the
top of the interior container.
To do this, place the freezer tray
containing the accumulator in
one of the top baskets.
If the freezer tray continues to
be needed as a partition, place
the accumulator in the basket di-
rectly on top of the frozen goods.
