38
EN
Basic functions
Steam function
Use this function to cook all sorts of vegetables, rice, cereals and meat. It is also suitable for extracting
juice from berries and for simultaneous defrosting and cooking of vegetables.
1. Press the “On/Off” key to switch the oven on.
2. Press the “Steam Function” key. The function key
lights up.
3. Press the “–” and “+” keys to set the temperature.
4. Press the “>” button to insert the time definitions.
5. Press the “–” and “+” keys if you want to set the
desired Operating Time. This setting is optional.
Please jump to point 7 if you don’t want to set
duration.
6. If you want to modify any of the above parameters,
press the “<” or “>” keys to select the parameter and
then the “–” and “+” keys to set a different value.
7. Press the Start key. The oven will start to operate.
Regenerating & Sterilising
Use this function to regenerate plate dishes and ready-made meals as well as to sterilise and boil
down fruit.
1. Press the “On/Off” key to switch the oven on.
2. Press the “Regenerating & Sterilising” key. The
function key lights up.
3. Press the “–” and “+” keys to set the temperature.
4. Press the “>” button to insert the time definitions.
5. Press the “–” and “+” keys if you want to set the
desired Operating Time. This setting is optional.
Please jump to point 7 if you don’t want to set
duration.
6. If you want to modify any of the above parameters,
press the “<” or “>” keys to select the parameter and
then the “–” and “+” keys to set a different value.
7. Press the Start key. The oven will start to operate.
Programme
Type of Food
Temperature ºC
Time (min)
Instructions
R 01
Plate dishes
100°C
13
R 02
Ready-made meals / frozen
100°C
18
Remove lid from container
and put on rack.
R 03
Beans
100°C
35
Sterilising:
The times and temperatures
refer to 1L preserving jars.
R 04
Cherries
80°C
35
R 05
Plums
90°C
35
