Material supplied

Remove all the components from the packets. Check that all the components are included.

• Hood assembled with motor, lamps and grease filters installed.

• 1 Pre-assembled truss

• 1 Filter connector with extensions

• Instructions for assembly and use

• 1 electrical cable

• 1 cable clamp

• 1 Assembly template

• 6 screws Ø 6x70

• 6 wall plugs Ø 10x60

• 14 screws Ø 4x7

• 42 screws Ø 3.5x9.5

• 2 adapter inserts

Installation - preliminary assembly instructions

The hood is designed for installation and use in “Extractor version” or in “Filter version”.

Note: the model with electric valve can only be used in “Extractor version” and the exhaust pipe must be

connected to a peripheral extraction unit.

Extractor Version

Fumes are extracted and expelled to the outside through an exhaust pipe (not supplied) fixed to the hood

exhaust pipe connector.

Depending on the exhaust pipe purchased, provide for suitable fixing to the exhaust pipe connector.

IMPORTANT: If already installed, remove the carbon filter/s.

Filter Version

Air is filtered through the carbon filter/s and recycled into the surrounding environment.

IMPORTANT: Check that air recirculation is ensured.

If the hood does not have the carbon filter/s, order one/them and fit before use.

Install the hood away from very dirty areas, windows, doors and heat sources.

The hood comes with all the materials necessary for installation on the majority of walls/ceilings. However,

a qualified technician must ensure that the materials are suitable according to the type of wall/ceiling.
