10
Use
The hood is conceived for the suction of cooking fumes and
steam and is destined only for domestic use.
The hood has been made for use in the internal recirculating
filtering version.
Cooking fumes and steam are aspirated inside the hood,
filtered and cleaned, passing through the fat filter/s and the
carbon filter/s that MUST be supplied with the hood.
When installing the hood in extracting version, you must
remove the air outlet grid, fixed as shown in Fig.8.
Installation
The minimum distance between the supporting surface for the
cooking equipment on the hob and the lowest part of the
range hood must be not less than 65cm from electric cookers
and 65cm from gas or mixed cookers.
If the instructions for installation for the gas hob specify a
greater distance, this must be adhered to.
Electrical connection
The mains power supply must correspond to the rating
indicated on the plate situated inside the hood. If provided with
a plug connect the hood to a socket in compliance with current
regulations and positioned in an accessible area, after
installation. If it not fitted with a plug (direct mains connection)
or if the plug is not located in an accessible area, after
installation, apply a double pole switch in accordance with
standards which assures the complete disconnection of the
mains under conditions relating to over-current category III, in
accordance with installation instructions.
Warning! Before re-connecting the hood circuit to the mains
supply and checking the efficient function, always check that
the mains cable is correctly assembled.
Warning! Power cable replacement must be undertaken by
the authorised service assistance centre or similar qualified
person.
Mounting
This type of cooker hood must be fixed to the ceiling.
Very heavy product; hood handling and installation must
be carried out by at least two persons.
Before beginning installation:
• Check that the product purchased is of a suitable size for
the chosen installation area.
• Check (for transport reasons) that there is no other
supplied material inside the hood (e.g. packets with
screws (*), guarantees (*), etc.), eventually removing
them and keeping them.
• If possible, disconnect and move freestanding or slide-in
range from cabinet opening to provide easier access to
rear wall/ceiling. Otherwise put a thick, protective
covering over countertop, cooktop or range to protect
from damage and debris. Select a flat surface for
assembling the unit. Cover that surface with a protective
covering and place all canopy hood parts and hardware
in it.
• In addition check whether near the installation area of the
hood (in the area accessible also with the hood mounted)
an electric socket is available.
• Carry out all the masonry work necessary (e.g.
installation of an electric socket).
Expansion wall plugs are provided to secure the hood to most
types of walls/ceilings. However, a qualified technician must
verify suitability of the materials in accordance with the type of
wall/ceiling. The wall/ceiling must be strong enough to take
the weight of the hood. Do not tile, grout or silicone this
appliance to the wall. Surface mounting only.
Identify on the ceiling a reference point from the exact
installation center of the hood (see fig. 1), and then trace the
reference points for the holes to be made in accordance with
the dimensions shown in Fig. 2.
Make the holes in the ceiling using a suitable twist drill bit with
8 mm diameter and insert the supplied plugs.
Approach the hood to the ceiling and make the electrical
connection.
Open the stainless steel panel placed on the underside of the
product, where the four lamps are located.
The opening of the panel is made by pulling on the side
corresponding to the air outlet grill. (Fig. 3).
Support the panel with your hands while opening it.
After the opening of the panel you can access the grease filter
and after removing it, by acting on the handle, you can reach
the seat of the charcoal filter (Fig. 4)
Place the hood on the set position and secure it with the
supplied screws, see Figure 5.
Place the charcoal filter in its seat as shown in Figure 6.
Restore the grease filter removed earlier and close the steel
panel.
To close the panel, simply bring it back to the horizontal
position until the automatic hooking of the closing takes place.
