ADDICTION INSTRUCTIONS FOR RECEIPT

BOARD

Please make sure the install direction and wire-plus position should be the same as the follwing picture, or the

UFO cannot work normally.

1. Press the turn-over button on the transmitter, the UFO can over

turn 360 drgee during ying.

2. press the the turn-over button at the left side of the controller,

a sound of “Di Di...’’will be heard, which means the ying dish

gets into rolling mode. At that time, pull the switch to forward,

backward, right or left and let go, the ying dish will turn 360

degree to corresponding direction. The rolling mode will turn o

automaticly.

WARNING!

Enough room is need for this motion, or danger may occur.

Socket 1 - Connect with right-front electrict wire.

Socket 2 - Connect with left-front electrict wire.

Socket 3 - Connect with left-back electrict wire.

Socket 4 - Connect with right-back electrict wire.

Press

this button

Press this button

Back

Right

Front

Left

Camera socket

LED lamp holder
