Quick Start Guide4

English

Using the Orion headset and its microphone

Connect the microphone and headphone plugs into the respective ports of

your computer or to the ROG Spitre. Extend the microphone and position

it close to your mouth when in use.

• Adjust the headband so it ts snugly on your head.

• Adjust the ear cups so it ts comfortably around your ears.

• Move the volume control to increase/decrease the volume.

Wearing your headset

There are L and R markings on the ear cups.

Specications

Driver dimensions: 50mm with neodymium magnet

Ear Cup Diameter: 100mm

Impedance: 32 ohms+15%

Frequency response: 20~20 k Hz

PNC (Passive noise

cancellation) performance:

Maximum >30dB

Dimension (mm): 189.85mm (W) x 187.87mm (H) x

103.82mm(D)

Weight (without cables): 268g

Using your headset with the USB dongle

1. Plug the headset’s microphone and output cable to their respective jacks

on the USB dongle.

2. Plug the USB dongle into your computer’s USB port. Driver installation is

not required.

3. Go to the Control Panel and audio settings to change the default input /

recording device.

Using Gaming / Surround / Amp modes on the USB

dongle

Press the Gaming / Surround / Amp button on the USB dongle to enable/

disable each audio mode.
