Telefunken TF-MID801G [8/35] Operation

Operation

Connections

Connecting to Wi-Fi

• Click the applications menu button (4) in

the top right corner of the main screen, in the

tab “Applications” select “Settings”. In section

“Wireless & Networks” click Wi-Fi to set into the

ON position.

• Connecting to the network: The system

automatically detects available Wi-Fi-networks

and displays their names; select a network you

want to connect and, if necessary, enter the

password. When the connection is successful,

the display shows the Wi-Fi icon (11) in the

notification area. The number of blue sectors of

the icon shows the level of Wi-Fi signal.

To add a Wi-Fi network to the list, click

“Add Network” in the top right corner, then use

the pop-up keypad to enter the network name

and click “Save”.

After disabling Wi-Fi please switch 3G

module off and hen turn it on again.

3G connectivity

Insert a 3G SIM-card into the appropriate

slot of the unit. Click the applications menu

button (4) in the top right corner of the

main screen, in the tab “Applications” select

“Settings”. In “Wireless & Networks” select

“More ...”. Click on “Mobile Networks”, put a

tick next to «Modem power» and enter the PIN-

code. In the “Mobile network settings”, select

“Access Point». Select your access point from

the list or adjust manually. When a successful

connection is performed, icon appears in

the system tray.

• When using a device with 3G, while

out of network coverage, you must disable

the transmission of data in order to free the

system from constant attempts to register in

the network. This is recommended to prevent

braking system and a long battery life.

• Impossibility of 3G-connection can be

caused by the lack of 3G coverage in place

where you are staing, and in this case it is not

a defect of the device.

A-GPS

• A-GPS function enables you to

determine the coordinates of the location of

mobile devices and display it on the map.

Determination of location is performed via

cellular connection channel and/or Wi-Fi.

• Click the applications menu button (4) in

the top right corner of the main screen, in the

tab “Applications” select “Settings”. In “Location

services” put a tick next to the option “Google’s

location service” and remove the tick for the

option “GPS satellites». Now when you start

working with map application (Google Maps),

after clicking on the icon the map will

display the location of your device.

Connect the external USB-drive

• Connect an external USB-drive with a

miniUSB cable to the MiniUSB or USB (Host)

port of this unit. Run the application “Explorer»

and select «USB» to access the contents of

the connected drive.

• You can connect other peripheral USB-

devices (e.g. mouse, keyboard, external hard

drives). It’s enough to connect the peripheral

device to the tablet, the device will be

recognized and connected automatically.

According to the USB 1.1/2.0 Standard,

usage of a USB device with power current

consumption exceeding 500 mA is not

recommended without supplementary power

supply. Failure to use supplementary power for

connected USB drives with power consumption

exceeding this value as well as defective

USB drives may cause mechanical or thermal

changes of elements of this unit as well as

failure of internal elements of the USB port.

Such damages are not warrantee cases.

Warning: usage of external USB drives

containing BIN files in the root directory may

cause malfunction of the unit or damage to the

software.

Connect the memory card

The tablet PC is equipped with a slot for

Telefunken TF-MID801G [8/35] Operation
