Dismounting (see figures B1–B2)

– Turn the release ring 4 in rotation direction  and pull the cutting

adapter off toward the front ().

– Afterwards, mount the rubber cap 9 onto the screwdriver again.

Changing the Blade (see figures C1–C2)

Note: Replace the blade only when the cutting adapter is mounted on the

screwdriver. This ensures that the tool spindle is locked and the blade

screw can be loosened.

– Set the rotational direction switch 5 to the middle position.

– Unscrew the blade screw 7 in rotation direction .

– Lightly lift the blade 8 and pull it down and out.

– Attach the new blade onto the tool holder ensuring that the ground

edge of the blade faces you.

Pay attention that the blade engages onto the tool holder.

– Retighten the blade screw 7 in rotation direction .

Operation

Starting Operation

To save energy, only switch the power tool on when using it.

Reversing the rotational direction

IXO (3 603 JA8 0..) (see figure D1)

– To set right rotation on the screwdriver, slide the rotational direction

switch 5 all the way forward.

IXO (3 603 J81 0.., 3 603 J59 3..) (see figure D2)

– To set right rotation on the screwdriver, press the rotational direction

switch all the way in from the right.

Switching On and Off

–To start the cutting adapter, press the On/Off switch 6 of the screw-

driver and keep it pressed.

–To switch off the cutting adapter, let go of the On/Off switch 6 of the

screwdriver.
