Not for
Reproduction
REF. PART REF. PART R E F. PA RT
NO. NO. DESCRIPTION NO. NO. DESCRIPTION NO. NO. DESCRIPTION
09P700
Illustra tions cover a range of engines . Parts shown without correspondi ng text may not be used on your specific engine.
10242--8 Assemblies include all parts shown in frames. 11/27/2012
8
1 590519 Cylinder Assembly
3 299819s Seal--Oil
(Magneto Side)
4 590569 Sump--Engine
5 590525 Head--Cylinder
7 799586 Gasket--Cylinder Head
11 590522 Tube--Breather
12 799587 Gasket--Crankcase
13 590512 Screw
(Cylinder Head)
16 590538 Crankshaft
-- -- -- -- -- -- N o t e -- -- -- -- -- --
590537 Crankshaft
Used on Type No(s).
0011, 0012, 0013,
0014, 0015, 0016,
0017, 0018, 0019,
0028, 0029, 0031,
0042, 0043, 0044,
0046, 0049, 0050,
0054, 0056, 0060,
0062, 0065, 0071,
0072, 0084, 0085,
0086, 0092, 0093,
0094, 0095, 0096,
0097, 0102, 0105,
0106, 0109, 0111,
0112, 0113, 0114.
591152 Crankshaft
Used on Type No(s).
0037, 0047.
20 391483s Seal--Oil
(PTO Side)
22 692551 Screw
(Crankcase
Cover/Sump)
22A 590763 Screw
(Crankcase
Cover/Sump)
23 590544 Flywheel
23A 592005 Flywheel
24 222698s Key--Flywheel
25 590521 Piston Assembly
(Standard)
26 590523 Ring Set
(Standard)
27 691588 Lock--Piston Pin
28 699659 Pin--Piston
29 590518 Rod--Connecting
32 691664 Screw
(Connecting Rod)
33 590531 Valve--Exhaust
34 590530 Valve--Intake
35 590532 Spring--Valve
(Intake)
36 590532 Spring--Valve
(Exhaust)
37 590582 Guard--Flywheel
-- -- -- -- -- -- N o t e -- -- -- -- -- --
591904 Guard--
Flywheel
Used on Type No(s).
0088, 0105, 0106,
0108, 0109, 0110,
0111, 0113, 0114,
0118.
40 590528 Retainer--Valve
43 697799 Slinger--Governor/Oil
45 590514 Tappet--Valve
46 590524 Camshaft
58 591108 R
ope
--Starter
60 691915 Grip--Starter Rope
60A 281434s Grip--Starter Rope
60B 799716 Grip--Starter Rope
75 590546 Washer
(Flywheel)
78 793480 Screw
(Flywheel Guard)
104 590558 Pin--Float Hinge
117 591999 Jet --Main
(Standard)
-- -- -- -- -- -- N o t e -- -- -- -- -- --
591998 Jet--Main
(Standard)
Used on Type No(s).
0001, 0003, 0005,
0006, 0007, 0010,
0024, 0033, 0045,
0046, 0047, 0055,
0075, 0087, 0098,
0104, 0115.
591997 Jet--Main
(Standard)
Used on Type No(s).
0002, 0004, 0008,
0009, 0025, 0027,
0036, 0037.
118 591996 Jet --Main
(High Altitude)
-- -- -- -- -- -- N o t e -- -- -- -- -- --
591995 Jet--Main
(High Altitude)
Used on Type No(s).
0001, 0003, 0005,
0006, 0007, 0010,
0024, 0033, 0045,
0046, 0047, 0055,
0075, 0087, 0098,
0104, 0115.
591994 Jet--Main
(High Altitude)
Used on Type No(s).
0002, 0004, 0008,
0009, 0025, 0027,
0036, 0037.
121 590589 Kit--Carburetor
Overhaul
122 590549 Spacer--Carburetor
125 591109 Carburetor
-- -- -- -- -- -- N o t e -- -- -- -- -- --
799584 Carburetor
Used on Type No(s).
0001, 0003, 0005,
0006, 0007, 0010,
0024, 0033, 0045,
0046, 0047, 0055,
0075, 0098, 0104,
0115.
125A 591110 Carburetor
Used on Type No(s).
0011, 0012, 0015,
0017, 0021, 0023,
0028, 0029, 0034,
0040, 0043, 0048,
0056, 0057, 0058,
0064, 0065, 0066,
0067, 0068, 0069,
0070, 0079, 0084,
0088, 0094, 0095,
0096, 0097, 0100,
0101, 0106, 0108,
0109, 0114, 0118.
-- -- -- -- -- -- N o t e -- -- -- -- -- --
590556 Carburetor
Used on Type No(s).
0002, 0004, 0008,
0009, 0025, 0027,
0036, 0037.
590555 Carburetor
Used on Type No(s).
0087.
