Not for
Reproduction
REF. PART REF. PART R E F. PA RT
NO. NO. DESCRIPTION NO. NO. DESCRIPTION NO. NO. DESCRIPTION
09P700
Illustrations cover a range of engines. Parts shown without corresponding text may not be used on your specific engine.
10242--9 Assemblies include all parts shown in frames. 11/27/2012
9
133 591120 Float--Carburetor
155 590529 Plate--Cylinder Head
163 799580 Gasket--Air Cleaner
187 791766 Line--Fuel
(Cut To Required
Length)
188 793480 Screw
(Control Bracket)
192 590535 Adjuster--Rocker Arm
202 590517 Link--Mechanical
Governor
209 590541 Spring--Governor
-- -- -- -- -- -- N o t e -- -- -- -- -- --
591497 Spring--
Governor
Used on Type No(s).
0057, 0058, 0067,
0068, 0069, 0070,
0072, 0075, 0080,
0081.
216 590547 Link--Choke
217 590740 Spring--Choke Return
222 590560 Bracket--Control
222A 590561 Bracket--Control
227 590520 Lever--Governor
Control
238 590533 Cap-- Valve
265 690798 Clamp--Casing
265A 691024 Clamp--Casing
267 691044 Screw
(Casing Clamp)
268 691025 Casing--Control Wire
(Cut To Required
Length)
269 691026 Wire--Control
(Cut To Required
Length)
270 691027 Nut
(Control Wire Casing)
271 691028 Lever--Control
300 590563 Muffler
300A 590564 Muffler
Used on Type No(s).
0034, 0057, 0058,
0065, 0087, 0106.
300B 590565 Muffler
305 590586 Screw
(Blower Housing)
318 793480 Screw
(Mounting Bracket)
332 690662 Nut
(Flywheel)
333 799582 Armature--Magneto
334 691061 Screw
(Magneto Armature)
337 692051 Plug--Spark
-- -- -- -- -- -- N o t e -- -- -- -- -- --
491055s Plug--Spark
Used on Type No(s).
0007, 0008, 0009.
797434 Plug--Spark
Used on Type No(s).
0015.
692720 Plug--Spark
Used on Type No(s).
0011, 0014, 0016,
0017, 0018, 0022,
0028, 0049, 0054,
0084
,
0085, 0100,
0112.
356 692390 Wire--Stop
358 590590 Gasket Set--Engine
363 19069 Puller--Flywheel
383 19576s Wrench--Spark Plug
404 690272 Washer
(Governor Crank)
445 798452 Filter--Air Cleaner
Cartridge
455 590545 Cup--Flywheel
493 590551 Bracket--Mounting
(Carburetor)
505 793515 Nut
(Governor Control
Lever)
522 590580 Plug--Dipstick/Fill
523 796503 Dipstick
524 691876 Seal--Dipstick Tube
528 793006 Hose--Primer
(Cut to Required
Length)
535 799579 Filter--Air Cleaner
Foam
562 793514 Bolt
(Governor--Control
Lever)
601 791850 Clamp--Hose
613 590562 Screw
(Muffler)
615 690340 Retainer--Governor
Shaft
616 590516 Crank--Governor
617 270344s Seal--O Ring
621 692310 Switch--Stop
623 799581 Seal--O Ring
(Carburetor Spacer)
635 692076 Boot--Spark Plug
676A 799187 Deflector--Muffler
718 690959 Pin--Locating
(Crankcase Cover)
724 697478 Retainer--Seal
741 796210 Gear--T iming
(Plastic)
745 691146 Screw
(Brake)
745A 690859 Screw
(Brake)
770 591139 Kit--Rewind/Blower
Housing
770A 592049 Kit--Rewind/Blower
Housing
Used on Type No(s).
0084, 0085, 0101,
0107, 0115.
832 590566 Guard--Muffler
832B 590567 Guard--Muffler
836 690661 Screw
(Muffler Guard)
836A 793500 Screw
(Muffler Guard)
842 691876 Seal--O Ring
(Dipstick Tube)
847 590572 Dipstick/Tube
Assembly
850 100106 Sealant--Silicone
857
591
113 Trim--Blower Housing
Cover
857A 591114 Trim--Blower Housing
Cover
