Page A

235e, 240e

CHAIN BRAKE ASSY 545 071101

Pos. Description

Compl No.

(pos no.)

Part No. Qty Notes

2 ASSEMBLY KNOB EZT 545-146401 1

3 PIN, DOWEL 20 530-057950 1

4 ASSY, FRONT LINK 20 530-057940 1

5 M3.83 X 1.81 X 9 PLASTITE 20 530-015911 1

6 SPRING COMPRESSION 20 530-016415 1

8 PIN, BAND RETAINER 20 530-015913 1

9 BRAKE BAND 20 530-057923 1

10 COVER, BRAKE BAND 20 545-071001 1

11 SCP#6-19 X .437 .PL. PAN. 20 530-016064 3

12 GEAR, IDLER 20 545-060201 1

13 WHEEL, GEAR ADJUSTER 20 545-090502 1

14 PIN, BAR ADJUSTING 20 545-060501 1

15 ASSY ADJUSTER SCREW 20 545-065901 1

16 COVER, GEAR 20 545-059201 1

17 SCP#6-19 X .437 .PL. PAN. 20 530-016064 3

18 CLIP, EZT SPRING 20 545-149301 1

19 DECAL, EZT CLUTCH COVER 545-118601 1

20 CHAIN BRAKE ASSEMBLY 545-071101 1 INCL. 3-6, 8-18
