235/235e/240/240e

CLUTCH AND OIL PUMP

Pos. Description

Part No. Qty Notes

1 ASSY- CLUTCH 530-014949 1

2 WASHER, CLUTCH (LARGE) 530-015611 1

3 3/8-6 TOOTH DRUM ASEMBLY 530-047061 1

3 .325-7 TOOTH DRUM ASEMBLY 530-048132 1

5 WASHER, THRUST 530-015907 1

6 ASSEMBLY OIL PUMP 545-069301 1

8 GEAR- WORM 530-037820 1

11 OIL BLOCK 545-069201 1

12 ELBOW FITTING 530-049477 1

13 PICK UP ASSEMBLY OIL TANK 545-069501 1 INCL 14,15

14 PICK-UP SEAL 13 545-069401 1

15 SPRING, FILTER 13 530-056533 1

16 SCP#6-19 X .437 .PL. PAN. 530-016064 2
