Lenovo TIO 27 (10YFRAT1EU) [28/54] Adjusting your monitor image

Chapter 2. 2-10

Adjusting your monitor image

This section describes the user control features used to adjust your monitor image.

Using the user controls

Your monitor has four user controls on the front panel. To locate the user controls, see "Locating

connectors and controls on your monitor"on page 1-4. You can use the user controls to adjust some

settings of your monitor on the On Screen Display (OSD) main menu.

• Back button

Used to move back and exit from the OSD menu.

• Left shift button / Mode-switching button

Used to move to the left on the OSD menu and switch between the AIO mode (using the Tiny

installed) and the DP/HDMI mode (using an external desktop/laptop computer).

• Right shift button / brightness control

Used to move to the right on the OSD menu and adjust the brightness.

• Selection button / menu-opening button

Used to open the OSD main menu and select an option.

Using the OSD controls

The settings adjustable with the user controls are viewed through the OSD, as shown below.

Note: When switching to AIO mode, the monitor and the Tiny share the same power button on the

monitor, However, if the enhanced power saving mode is enabled in the BIOS of the Tiny, you can

only use the power button of the computer to turn on the computer.

To use the controls:

1. Press to open the main OSD menu.

2. Use or to move among the icons. Select an icon and press to access that

function. If there is a sub-menu, you can move between options using or , then

press to select that function. Use or to make adjustments 3ress to save.

3. Press to move backwards through the sub-menus and exit from the OSD.

4. Press and hold for 10 seconds to lock the OSD. This will prevent accidental

adjustments to the OSD. Press and hold for 10 seconds to unlock the OSD and allow

adjustments to the OSD.

5. Enables DDC/CI by default. Use OSD Left Arrow Key, press and hold the buttons for 5

seconds to disable/enable DDC/CI function. The words "DDC/CI Disable/DDC/CI

/Enable" shows on the screen.

Exit

Adjusts overall screen Brightness/Contrast/DCR
