Chapter 3. 3-4
Monitor specifications
Table 3-1. Monitor specifications for type-model 10YF-RAR1-WW
Dimensions Depth
Height
Width
329.0 mm (12.95 in.)
444.25 mm (17.49 in.)
614.0 mm (24.17 in.)
Stand Tilt range Range: -5°/+30°
Stand Swivel Range: -45°, +45°
Stand Pivot Range: -5°, 90°
Stand Lift Range: 110.0 mm
VESA mount Supported 100 mm (3.94 in.)
Image Viewable image size
Maximum height
Maximum width
Pixel pitch
685 mm (27 in.)
336 mm (13.2 in.)
597 mm (23.5 in.)
0.2331mm (H) x 0.2331 mm (V)
Power input
Power consumption
Note: Power consumption
figures are for the monitor and
the power supply combined
Supply voltage
Max supply current
Max Consumption
Typical Consumption
Standby/Suspend
Off
20VDC
8.5 A
57 W (max)
37 W (typ)
<0.5 W
<0.4 W
Video input Interface
Horizontal addressability
Vertical addressability
Clock frequency
DP/HDMI
2560 pixels (max)
1440 lines (max)
241.5 MHz (max)
Communications VESA DDC CI
Altitude Test Operation 16404.2 ft
Supported Display Modes
(VESA Standard modes
between noted ranges)
Horizontal frequency
Vertical frequency
Native Resolution
DP/HDMI: 30 kHz – 99 kHz
50 Hz – 76 Hz
2560 x 1440 at 60 Hz
Temperature Operating
Storage
Shipping
0° to 40°C (32°F to 104° F)
-20° to 60°C (-4°F to 140° F)
