English
37
X570 Taichi
2.7 Smart Switches
e motherboard has four smart switches: Power Button, Reset Button, Clear
CMOS Buttons and BIOS Flashback Switch, allowing users to quickly turn on/o
the system, reset the system, clear the CMOS values or ash the BIOS.
Power Button
(PWRBTN)
(see p.8, No. 21)
Power Button allows users
to quickly turn on/o the
system.
Reset Button
(RSTBTN)
(see p.8, No. 22)
Reset Button allows
users to quickly reset the
system.
Clear CMOS Buttons
(CLRCBTN1)
(see p.10, No. 14)
(CLRCBTN2)
(see p.8, No. 19)
Clear CMOS Buttons
allow users to quickly
clear the CMOS values.
Power
Reset
is function is workable only when you power o your computer and unplug the power
supply.
