English
32
RGB LED Header
(4-pin RGB_HEADER1)
(see p.7, No. 5)
RGB LED header is used to con-
nect RGB LED extension cable
which allows users to choose
from various LED lighting ef-
fects.
Caution: Never install the RGB
LED cable in the wrong orienta-
tion; otherwise, the cable may
be damaged.
*Please refer to page 49 for for
further instructions on these two
headers.
AMD FAN LED Header
(4-pin AMD_FAN_
LED1)
(see p.7, No. 6)
AMD FAN LED Header is used
to connect RGB LED
extension cable that comes with
AMD heatsink. e cable
connection allows users to choose
from various LED lighting
eects.
Caution: Never install the FAN
LED cable in the wrong orienta-
tion; otherwise, the cable may
be damaged.
12V G R B
1
12V G R B
1
