Tesla TT22EXC1-0732IA [55/64] Information for the installer

55

ENG

Outdoor unit test

• Is there any abnormal noise or vibration during operation?

• Could the noise , the air flow or the condensed water drainage disturb the neighbours?

• Is there any coolant leakage?

Note: the electronic controller allows the compressor to start only three minutes after voltage has reached the

system.

INFORMATION FOR THE INSTALLER

1

R410A R410A

1

Refer to the data rating label sticked on the outdoor unit.

MODEL capacity (Btu/h) 9k/12k 18k/24k

Lenght of pipe with standard charge 5m 5m

Maximum distance between indoor and outdoor unit 25m 25m

Additional refrigerant charge 15g/m 25g/m

Max. diff. in level between indoor and outdoor unit 10m 10m

Type of refrigerant

PIPE

1/4" (ɸ6) 15 - 20 wrist strength Service port nut 7 - 9

3/8” (ɸ9.52) 31 - 35 arm strength Protection caps 25 - 30

1/2” (ɸ12) 35 - 45 arm strength

5/8” (ɸ15.88) 75 - 80 arm strength

PIPE
