Before you call for service...
Troubleshooting Tips
Save time and money! Review the chart below first and
you may not need to call for service.
Normal Operation
You may hear a pinging noise caused by water being picked up and thrown against the condenser
on rainy days or when the humidity is high. This design feature helps remove moisture and improve
efficiency.
You may hear the thermostat click when the compressor cycles on and off.
Water will collect in the base pan during high numidity or on rainy days. The water may overflow
and drip from the outdoor side of the unit.
The fan may run even when the compressor does not.
Abnormal Operation
Problem
Possible CausesPossible CausesPossible Causes
What To DoWhat To DoWhat To Do
Air conditioner
does not start
The air conditioner is
unplugged.
The fuse is blown/circuit
breaker is tripped.
Power failure.
Air conditioner
does not cool as it
should
Airflow is restricted.
THERMOSTAT control set
too warm.
The air filter is dirty.
The room may have been
hot.
Cold air is escaping.
Cooling coils have iced up.
Air conditioner
freezing up
Ice blocks the air flow and
stops the air conditioner
from cooling the room.
Make sure the air conditioner plug is pushed
completely into the outlet.
Check the house fuse/circuit breaker box and
replace the fuse or reset the breaker.
If power failure occurs, turn the OPERATION control
to OFF( O ) . When power is restored, wait 3 minutes
to restart the air conditioner to prevent tripping of the
compressor overload.
Make sure there are no curtains, blinds, or furniture
blocking the front of the air conditioner.
Turn the THERMOSTAT knob clockwise to a cooler
setting.
Clean the filter at least every 2 weeks.
See the operating instructions section.
When the air conditioner is first turned on you need
to allow time for the room to cool down.
Check for open furnace floor registers and cold air
returns.
Set the air conditioner's vent to the closed position.
See Air Conditioner Freezing Up below.
Set the OPERATION control at fan ( ) or
HIGH cool ( ) with the THERMOSTAT at the warmer
position or the temperature at more than 23°C.
Installation Instructions
-11-
